Summary

  • Electronic cleanroom passthrough with Smart® Control System provides advanced control and monitoring
  • Obstruction free interior, lipless edges, radius corners, continuous welds for strict disinfection
  • Quick and easy flush-mount design is hassle-free and installs in under 3 minutes (see video)
  • Hidden electronic interlock allows only one door to open at a time to prevent cross-contamination
  • Countless add-on capabilities: automatic doors, access security systems, UV disinfection, and more
  • Cleanroom pass throughs reduce foot traffic, improve cleanliness, safety, productivity, and much more.
  • Chamber Design:
  • Designed for sterile, regulated bio-pharmaceutical applications.
  • Electronic door interlock allows for unique, custom door swing configurations such as 90 degree corners (L-shape chambers), 3-door designs (T-shape chambers), 4-door designs (X-shape chambers), and more.
  • All-316L stainless steel surfaces with enhanced corrosion resistance stand up to harsher cleaning agents and withstand degradation from bleach-based disinfectants.
  • Continuous welds with coved radius corners and lip-less edges eliminate hard-to-clean cracks and crevices where contaminants can collect.
  • Double-wall construction greatly increases rigidity and durability of the pass through chamber to facilitate installation and prevent warping on larger chambers.
  • Flush-mount design removes dust accumulating surfaces inside the cleanroom.
  • Optional dual BioSafe® stainless steel racks easily remove for cleaning or sterilizing and are reversible to allow slide-out motion in either direction.
  • Quick and Clean Installation:
  • Innovative fastening system clamps to a variety of wall thicknesses without penetrating or damaging the finished surrounding wall.
  • The mounting frame is covered on both sides for an easy-to-clean finish with no visible fasteners or screws.
  • Easy-to-install mounting system also allows the entire passthrough chamber to be seamlessly removed and reinstalled within minutes, without damaging the surrounding wall.
  • Electronic Automatic Door Interlock:
  • Hidden Smart® control panel is mounted outside the transfer chamber (between double-wall) for easy-to-clean obstruction-free chamber interior.
  • Electronic interlock with Smart® Control System provides visual and audible door status alerts to prevent door damage that results when users exert excess force on an engaged interlock:
  •        Green light indicates both doors available for use.
  •        Red light and dual-side remote chimes indicate a door is open and interlock engaged.
  • Door Design:
  • Access doors with 316L stainless steel reinforced frames extend passthrough chamber's service life and provide a tight seal.
  • Santoprene® “e”-shape non-outgassing rubber gasket firmly compresses to eliminate leaks. The one-piece resilient rubber gasket maintains its shape after compression and won't flatten, warp, crack, or degrade like ordinary foam gasket. Gasket is also mechanically attached to the door frame to avoid adhesive failure common with gasket tapes.
  • Doors are leak-rated by UL for tight seal to maintain cleanroom pressure gradients.
  • Heavy-duty stainless steel lift latches included to minimize scratching, corrosion and contamination resulting over time that can occur with chrome-plated latches.
  • Sturdy "lift-off" stainless steel hinges are welded to the door frame and chamber. They are detachable to allow doors to easily lift off for trouble-free replacement or more thorough cleaning/decontamination.
  • Order replacement door(s) to avoid critical operation delays should a door be damaged and require immediate replacement.
  • Includes:
  • (1) Main power cord, to be hardwired to power supply onsite per local code by a licensed electrician.
  • (1) Automatic electronic interlock.
  • (2) Plug-in chimes (one for each side of the passthrough).
  • Mounting bracket system with cover plates. Standard mounting system accommodates 4”-6” wall thickness. Specify wall thickness at time of order.

Specifications

Special Door Configuration: Leak-Rated

Material: 316L Stainless Steel

Mounting Position: Flush Wall

Inside Width: 24"

Inside Depth: 24"

Inside Height: 24"

Expand System Capabilities: UV Sanitizer, Electronic Pass-Through Upgrade, 90° Corner Placement, LED Lighting, Automatic Door, Intercom, Iris Scanner, Keycard Reader, Fingerprint Scanner, Video Recording, Power Outlet, Load Presence Sensor, Access Control System, Air Speed Sensor, Access Panel, Message Panel, Slide-Up Doors

Window Material: PVC

Electropolished: Optional

Storage Racks: Optional

HEPA/ULPA Filtration: No

Unit of Measure: EA

Helena

Marks & Listings: UL, ULC

Electrical Specifications: 120 V, 50/60 Hz

Weight, Product: 215 lb

Dimensions, Product: 37.5" W x 24" D x 25.6" H

Weight, Shipping: 353 lb

Dimensions, Shipping: 39.25" W x 41" D x 42.5" H

Package Type: Crate

Smart® CleanMount® Pass-Through Chambers

  • Smart® Pass-Through Chambers by Terra Universal
  • Cleanroom passthrough chamber with 3 interlocking doors for USP 800 hazardous compounding Smart® Pass-Through with “T” Shape 3-Door Design for USP 800 Hazardous Compounding
  • Refrigerated Smart passthrough chamber with 90 degree corner for pharmacy cleanroom Refrigerated Smart® Passthrough with 90 Degree Corner to Transfer Active Pharmaceutical Ingredients
  • Smart Cleanroom Pass-Through with 90 Degree Corner and HEPA Filtration Smart Cleanroom Pass-Through with 90 Degree Corner and HEPA Filtration
  • this video shows how the hands-free operation of the automatic pass-through door minimizes the potential for touch contamination Hands-Free, Automatic Pass-Through Door
  • Smart Cleanroom Pass-Through Chamber with Models Smart Pass-Through Chamber, 24"W x 24"D x 24"H
  • Fire-Rated Passthrough Door Window with Model Fire-Rated Passthrough Chamber with Window
  • Automatic Door with Touchless Sensor Automatic Door with Touchless Sensor
  • Vertically stacked Smart passthrough chambers for stem cell lab Vertically Stacked Smart® Passthrough Chambers with HEPA Filtration on Top for Stem Cell Lab
this video shows how the hands-free operation of the automatic pass-through door minimizes the potential for touch contamination
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • LED Recessed Light

    Activates when either pass-through door opens; flush with the wall surface, covered by a static-dissipative PVC lens.
  • ULPA-Filtered Air Shower

    High-velocity, ULPA-filtered air dislodges surface-deposited contaminants and exits the chamber through a filtered exhaust.
  • Video Camera

    Interior HD video camera records continuously or upon door-opening; can also be used for remote monitoring the transfer chamber.
  • Infrared Load Sensor

    Infrared beams detect objects placed inside the transfer chamber and can be used to trigger an audible alert. The crossed red lines depict the non-visible trigger lines between the IR transmitters and receivers.
  • Iris Scanner

    Fully automated iris scanner for secure, hands-free access (includes datalogging and optional secondary keycard reader).
  • Automatic Door

    Hands-free operation of the pass-through door, governed by the electronic interlock; automatically closes based on delay timer.
  • Intercom System

    Built-in intercom system lets users easily call and communicate between rooms. No more knocking on windows, shouting, or awkward sign language.
  • LCD Message Panel

    Displays critical environmental information related to the interior chamber such as temperature and relative humidity (customizable).
  • UV Sanitizing Module

    Provides a timed cycle of 254 nm Ultra-Violet (UV) radiation to neutralize bacteria, viruses and mold spores within line-of-sight of the light fixture.
  • Support Brackets for Pass-Through Chambers

    Stainless steel support brackets are recommended for pass-throughs deeper than 24". Brackets fasten to the wall and the body of the chamber rests upon the horizontal bar; no fasteners are used on the pass-through itself.
  • Available UV & LED lights

    Lights are recessed with a transparent lens for easy cleaning; UV-C module neutrailizes microbes using a timed disinfection cycle.
  • 304 Stainless Steel Sliding Tray for Cleanroom Pass Through

    Securely hold small parts during transfer with this dual-motion sliding tray in corrosion-resistant 304 stainless steel. Tray attaches to sliding runners inside a pass-through to allow full tray extension in both directions for convenient material handling.
