- Available ISO Ratings: ISO 6, ISO 7, ISO 8
• Control Level: Tier 1
• Data Logging: Yes
• Display: 2.4"
• FFU Control: Remote
• Max # of FFUs: 50
• Max # of Rooms: 5
• Unit of Measure: EA
Cleanroom control panel with Tier 1 system monitors and controls up to 50 FFUs in 5 rooms; 6 inputs for pressure/RH/temp sensors, plus FFU performance alarm |
Control Panels & Power Distribution,Control Panels & Power Distribution
Read more
Terra Part #: 6607-01
Manufactured By: Terra Universal
Warranty: 1 year parts, 90 days labor
Print
Want a quote quickly ?
Submit a QuickQuote request
Summary
- • Available ISO Ratings: ISO 6, ISO 7, ISO 8
- Includes mirror-finished stainless steel control panel assembly installed at the cleanroom entrance and one LED status indicator installed in each cleanroom corner
- Control Panel assembly includes power controls for Fan/Filter Units, lights, and all system options (Designed for panels externally mounted)
- One required per cleanroom - additional units maybe specified for multiple entrances
- All electrical lines terminate in quick-connect fittings for easy installation
- Status indicator lights glow continuously to show FFUs are turned on and flash to indicate that FFUs are turned off
- Includes Tier 1 graphic console
Specifications
• Control Level: Tier 1
• Data Logging: Yes
• Display: 2.4"
• FFU Control: Remote
• Max # of FFUs: 50
• Max # of Rooms: 5
• Unit of Measure: EA
Helena
Features and Benefits
Pre-Installed Electrical Components
Pre-installed electrical components are housed in the power distribution module
Quick-Connect Fittings
FFUs and lights can be easily added as cleanrooms requirements change, or disconnected for maintenance, without the need to run additional power lines or involve an electrician.
Cleanroom Control Panel
Cleanroom Control Panels are typically mounted at the main entry of the cleanroom (custom model shown with Digihelic® room pressure gauges and thermo-hygrometers).
Operation Status Indicator Light
Modular Cleanrooms include a status indicator light in each corner, which glows when fan/filter units are operating and blinks when they are inactive.
Night Service Saves Energy, Extends Filter Life!
Night service switch, shown mounted on Modular Hardwall Cleanroom panel, puts FFUs in low-energy mode during off-hours; saves 25% of fan operating costs and extends filter life.
Products Compliant With Your ISO Rating
High-capacity, durable, ISO-compliant system rated for thousands of operating hours.
