Features and Benefits

ValuLine HLF Specifications

Valuline Horizontal Laminar Flow Workstations

Important Note: This work station is designed for particle-sensitive applications and does not protect operators against hazardous fumes, vapors or aerosols. See Terra's exhaust purification systems for operations involving hazardous fumes.

  • Construction: Fabricated from welded 16-gauge C.R. steel; includes adjustable levelers
  • Work Surface: 304 Stainless steel
  • Finish: Exterior surfaces feature a chip-resistant, powder-coat finish
  • Prefilters: Disposable fiberglass
  • Final Filters: Choice of HEPA (rated 99.99% efficient @ 0.3 µm particles) or ULPA (rated 99.999% efficient @ 0.12 µm particles)
  • Lighting: Fluorescent type. Recessed to eliminate air flow disturbance. Accepts lens for yellow light, if necessary
  • Fan/Motor: Brushless, 1/3-HP, electrically-commutated motor, centrifugal type with backward-inclined fans and sealed bearings; rated for continuous duty; furnished with overload protection
  • Average Airflow Velocity: 109 (± 10) FPM (0.55 m/s) at medium speed, measured 12" (305 mm) below filter face
  • FFU Air flow: 767 CFM (2'x4' model) - all models rated at 109 FPM (0.55 m/s) at medium setting under HEPA filter load
  • Sound level: 40 dBA, measured no more than 12"(305 mm) from filter face @ 109 FPM (0.55 m/s)
  • Performance: Dust count exceeds Class 10 requirements (per Fed-Std 209E)
  • Backpressure Gauge: Minihelic® gauge, 0 - 3" Water Column monitors backpressure across filter
  • Electrical: 115VAC, 50/60Hz, single phase (220VAC, 50/60Hz available). Consumes 280W/2.4A at the avg air speed. Meets the requirements of the National Electrical Code and applicable local codes. All components UL listed and CE marked
  • Options: Audible/visible filter alarm system (measures face velocity); ionizing system (including self-balancing power supply); petcocks for vacuum, DI water, or gas; electropolished stainless steel surfaces; special paint; special voltage and frequency

Minihelic® is a registered trademark of Dwyer Instruments incorporated
