Summary

• Ambient Temperature: 5 to 40°C

• For heating applications from +20 to +150 °C

• Immersion depth: 16.6” (421.64 mm)

• Temperature stability °C: ± 0.03

• Temperature Calibration: 1-point calibration (CD)

• Heating capacity kW: 1

• Pump Capacity Flow Rate: 15 (L/min)

• Pump Capacity Flow Pressure: 5.08 psi

• Setting/Display Resolution: 0.1 °C

• Temperature Display: LED

• Complies with Class III (FL) according to DIN 12876-1

• Internal and external (when used with #9 970 140 Pump Set) applications

• Bright, white and easy-to-read LED display

• Quiet, easy-to-operate

Optional: Cooling Coil

Applications: chemistry, pharmaceutics, medicine, analytics, material testing, temperature applications for samples and more

Specifications

Type: Immersion Bath

Temperature Range: 20 to 150°C

Tank Capacity: 50 L

Refrigerated: No

Heated: Yes

Power: 1000W

Family: Corio CD Head

Manufacturer SKU: 9012000

Unit of Measure: EA

Helena

Marks & Listings: 0-2

Electrical Specifications: 115 V, 1 Ph, 60 Hz

Weight, Product: 5 lb

Dimensions, Product: 5.25" W x 6.5" D x 14.25" H

Weight, Shipping: 8 lb

Dimensions, Shipping: 10.25" W x 11.5" D x 19.25" H

Package Type: Crate
