Part # 9505-43

Compressor; Scroll, 3 HP, 10 gal, 8.6 SCFM, 17.0 Amps, 230 V

  • Available ISO Ratings: ISO 7, ISO 8
  • Air Compressor operates maintenance free, with only two moving parts
  • Includes air-cooled after-cooler, run-hour meter, and power indicator light, run and high-temp
  • Vibration-free, quiet (49dB) operation
  • Motor overload protection, air pressure gauge, and high-temp switch
  • Dry type inlet filter ensures that air enters the unit 99% particle-free
Stocked ISO 7 Icon
$9,180
Part #: 9505-43
Usually ships in 5-7 business days

Want it faster ? Read about FasTrak

In stock

Product Details

  • •  Available ISO Ratings: ISO 7, ISO 8
  • Air Compressor operates maintenance free, with only two moving parts
  • Includes air-cooled after-cooler, run-hour meter, and power indicator light, run and high-temp
  • Vibration-free, quiet (49dB) operation
  • Motor overload protection, air pressure gauge, and high-temp switch
  • Dry type inlet filter ensures that air enters the unit 99% particle-free
  • Cooling fan keeps operating temperature low, extending the life for bearings and seals
  • Self-lubricating, long-life tip seal
  • Continuous air delivery
  • Single phase 3HP units will require installation of an additional 30 gal. external tank

Specs

• Type: Scroll

• Oil-less: Yes

• Power: 3 HP

• Tank Capacity: 10 gal

• System F.L.A.: 17.0 Amps

• Service Pressure (PSIG): 116 PSIG

• SCFM @ 100 PSIG: 8.6 SCFM

• Unit of Measure: EA

• Marks & Listings: UL

• Electrical Specifications: 230 V, 13 A, 2,990 W, 1 Ph, 50 Hz

• Weight, Product: 264 lb

• Dimensions, Product: 24" W x 25" D x 39" H

• Weight, Shipping: 269 lb

• Dimensions, Shipping: 28" W x 30" D x 44" H

• Package Type: Box
