Cleanroom control panel with built-in Tier 4 touchscreen console; datalogging (pressure/temp/RH) and FFU control for up to 16 rooms, 200 FFUs | 6607-04 displayed
Control Panels & Power Distribution,Control Panels & Power Distribution,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan Filter Units,Fan/Filter Units,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions,Cleanroom Conversions
Product Group:
6702-PP-01
6702-PP-01 72268

Smart® Control Panels for Fan Filter Unit (FFU) Systems

  • Available ISO Ratings: ISO 6, ISO 7, ISO 8
  • Smart cleanroom control panel intelligently monitors and controls clean rooms and facilities
  • Connects to EC FFUs for fan control plus monitors differential pressure, temperature, and/or RH
  • Plug-and-play design is field configurable to match your facility layout and needs
Read more
Stocked ISO 6 Icon
Manufactured By: Terra Universal
Print
Need Help?

(714) 578-6100

Hours Mon - Fri, 07:00 AM - 06:00 PM (Pacific Time)

Chat

Want a quote quickly ?
Submit a QuickQuote request

Select Product Options

Data Logging Control Level ISO Class Max # of Rooms Max # of FFUs Display FFU Control Price Usually Ships in Stocked
Yes Tier 1 ISO 6 5 50 2.4" Remote $6,116 30-36 Days
Yes Tier 2 ISO 6 6 100 3.5" Remote $5,855 1-3 Days Stocked
Yes Tier 2 ISO 6 6 N/A 3.5" N/A $5,855 1-3 Days Stocked
Yes Tier 3 ISO 6 12 120 7" Remote $7,351 30-36 Days
Yes Tier 4 ISO 6 16 200 12.1" Remote $9,117 30-36 Days
Yes Tier 1 ISO 6 5 50 2.4" Remote $6,116 30-36 Days
Yes Tier 2 ISO 6 6 100 3.5" Remote $5,323 30-36 Days
Yes Tier 2 ISO 6 6 N/A 3.5" N/A $5,323 30-36 Days
Yes Tier 3 ISO 6 12 120 7" Remote $7,351 30-36 Days
Yes Tier 4 ISO 6 16 200 12.1" Remote $9,117 30-36 Days

Summary

  • Available ISO Ratings: ISO 6, ISO 7, ISO 8
  • Smart cleanroom control panel intelligently monitors and controls clean rooms and facilities
  • Connects to EC FFUs for fan control plus monitors differential pressure, temperature, and/or RH
  • Plug-and-play design is field configurable to match your facility layout and needs
  • Four levels of monitoring and control help you meet critical performance requirements in your new cleanroom:
  • Tier 1 Control: Monitors up to 50 FFUs in up to five rooms on a 2.4" graphical display; includes six inputs for pressure, RH or temperature sensors, along with FFU performance alarm, calendar-controlled power saver mode, and local data logging via SD card.
  • Tier 2 Control: Monitors up to 100 Fan/Filter Units (FFUs) in up to eight rooms on a 3.5" LCD display; includes six inputs for pressure, RH or temperature sensors, along with FFU performance alarm and calendar-controlled power set-back to save power costs. Includes Ethernet for remote data logging and email alarm notification. Ideal for FDA, cGMP or USP-regulated applications!
  • Tier 3 Fully Automated Control: Fully dynamic FFU control maintains set-point pressure and air change rates room-by-room; includes data logging and 5.7" color touchscreen configured to your facility floor plan.
  • Retrofit Kits can be added to existing Terra cleanrooms to simplify air balancing and allow environmental data logging
  • Requires Smart® (EC) fan/filter units
  • Use Tier 3 for compliance with cGMP and USP requirements
  • Sensors available with NIST-traceable certification
  • Each system can be customized to fit individual budgets and requirements

Features and Benefits

Tier 4 Cleanroom Control Panel with Automated Monitoring and Control

Terra’s Tier 4 cleanroom control panel intelligently monitors and controls clean room and facility environments. Monitor differential pressure, temperature, and/or RH. The Tier 4 console supports cleanroom monitoring for up to 16 rooms and control of up to 200 FFUs. The plug-and-play design is field configurable to match your facility layout and needs.

Power Distribution Module for Modular Cleanroom

Terra’s Power Distribution Modules (PDMs) drastically simplify connection of fan/filter modules (FFUs) and ceiling lights, while providing low-voltage power for one or more Control Panels. The high-voltage power distribution system is UL-listed for the highest safety and quality.

Continuous Product Improvement

At Terra, we strive to develop and produce the highest quality products for our customers to improve health, safety, performance, and yields. Our product quality is enabled by high-grade manufacturing equipment and processes, 45 years of engineering and application expertise, and our commitment to continuously improve.

Products Compliant With Your ISO Rating

High-capacity, durable, ISO-compliant system rated for thousands of operating hours.
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Energy-Efficient LED Lighting Panels

    Energy-Efficient Lighting

    Energy-efficient LED lighting panels and strips help to lower electrical costs and minimize heat build-up in temperature-controlled environments.
