DesiCart™ Low-Humidity Transport Carts

• RH Controlled cart transport desiccators .

• Nitrogen purged with quick connect fittings

• Whole cart RH control

• Static-dissipative PVC or acrylic chambers

• Cart frame in polyethlene or SS

• 1, 2 or 4 chambers, 200 mm wafer variant

• SS framed doors

• Cabinets: 50.88" W x 26.25" D x 38" H

Manufactured By: Terra Universal

Need Help?

(714) 578-6100

Mon - Fri, 5:30 AM - 5:30 PM, PST

Email Chat

Want a quote quickly ?

Submit a QuickQuote request

Select Product

Chamber Material All Acrylic Static Dissipative PVC Sort Order: Descending Ascending	Number of Chambers All 2 Chambers 4 Chambers 1 Chamber Sort Order: Descending Ascending	Frame Material All Stainless Steel Polyethylene Sort Order: Descending Ascending	Price	Ships in
Acrylic	2 Chambers	Stainless Steel	$3,106	23-31 Days
Acrylic	4 Chambers	Polyethylene	$2,461	23-31 Days
Acrylic	1 Chamber	Stainless Steel	$5,056	23-31 Days
Static Dissipative PVC	2 Chambers	Stainless Steel	$3,698	23-31 Days
Static Dissipative PVC	4 Chambers	Polyethylene	$2,925	23-31 Days
Static Dissipative PVC	1 Chamber	Stainless Steel	$6,552	29-37 Days
Acrylic	1 Chamber	Stainless Steel	$5,493	29-37 Days

Chamber Material

Number of Chambers

Frame Material

Some ship in:

Usually Ships in:

Add to Compare

See Product Details

Back to product group

Select product to see details

Product Details

Features & Benefits

Products similar to this one

Manuals & Resources

Product Details

• Maintains low-humidity, low-particle conditions during materials transport

• Opposing access doors for pass-through convenience

• Reinforced door construction and durable, ergonomic LiftLatches

• Chemical-resistant materials stand up well to frequent cleaning

• Integral one-piece handles and wrap-up edges

• Electropolished stainless steel wire racks mounted inside the desiccator allow easy adjustment of optional stainless steel shelving

• Select clear acrylic or transparent static-dissipative PVC desiccator chamber

• Automatic RB® Valve (included) and optional Quick-Connect fitting facilitate dry gas purging and prevent over-pressurization

• All models feature 5" (127 mm)-diameter polyurethane swivel casters, two with wheel locks, for smooth quiet operation and ISO 5 cleanroom-compatibility

• Cushioned casters ensure smooth rolling over uneven surfaces

• Many standard configurations for wafer boxes, flat panel displays, chemicals, pharmaceuticals, and other sensitive materials

• Quick connect/disconnect fittings (optional) enable you to purge the system with nitrogen while it is stationary

DesiCarts

Standard Features

A Polyethylene (shown) or Stainless Steel Cart
Durable cart construction ensure long service life; both include marine edges to prevent spills
B Acrylic or Dissipative PVC
Static-Dissipative PVC eliminates surface charges and the particles they attract
C Stainless Steel Racks
Racks support optional shelving that accommodates varying part sizes
D Reinforced Doors
Stainless steel door frames extend the life of the DesiCart's most heavily used component
E Relief/Bleed Valve
Protects against overpressures when the cart is connected to nitrogen (closes to prevent air influx when disconnected from gas source)

Optional Features

1 QuickConnect Gas Fitting
Allows introduction of clean, dry nitrogen when cart is stationary (no humidity control while cart is in motion)

Add a QuickConnect fitting to charge up on dry nitrogen before transporting sensitive parts!

Cart Transport Desiccators

Nitrogen Generators
DesiCart Mobile Desiccator
DesiCart Low-RH Transport Cart
SDPVC Wafer Box DesiCart
Plastic DesiCart
Plastic Desicart Stainless Steel Frames
Plastic Desicart
Polyethylene Frame Acrylic Desicart
Extra-Large DesiCart

Nitrogen Generators provide a reliable source of clean, dry nitrogen, requiring only a compressed air source Nitrogen Generators Nitrogen Generators eliminates drawbacks of conventional nitrogen sources, and gives you control of rate and purity of nitrogen production. It gives you complete control of the production of nitrogen for use in a wide range of cleanroom applications.

Stainless steel desicarts are an optional feature that offers a steel frame with a SDPVC two chamber desiccator | 4001-91B displayed DesiCart Mobile Desiccator This DesiCart houses a sealed two-chamber desiccator storage chamber, which maintains clean, dry storage conditions during transport, installed in a stainless steel cart with a solid stainless steel top.

This Desicart features a polyethylene and stainless steel frame, along with a four chamber SDPVC desiccator | 4002-51B displayed DesiCart Low-RH Transport Cart High-Density Polyethylene DesiCarts provide excellent chemical resistance and include an integral one-piece handle. Wrap-up rails make for safe transport of materials carried on top of the cart, and corners are rounded for easy cleaning.

Wafer Box Desicart features a stainless steel frame, perforated shelves and door along with a SDPVC enclosure | 4002-48B displayed SDPVC Wafer Box DesiCart This DesiCart™ ensures clean, dry, secure transport of delicate wafers. Perforated shelves ensure uniform gas distribution. Their angled design keeps boxes securely in position during transit.

This Desicart is a four chamber, two tier mobile Static Dissipative PVC desiccator mounted in a high-density polyethylene cart for easy parts transfer | 4002-51B displayed Plastic DesiCart This DesiCart houses a sealed four-chamber desiccator storage chamber, which maintains clean, dry storage conditions during transport, installed in a non-corroding, high-density polyethylene cart with a solid top.

The Desicart is a desiccator (shown: static-dissipative PVC) enclosed in a stainless steel cart for easy parts transfer | 4001-90B displayed Plastic Desicart Stainless Steel Frames This DesiCart houses a sealed two-chamber desiccator storage chamber, which maintains clean, dry storage conditions during transport, installed in a stainless steel cart with a solid stainless steel top.

Four-chamber, two tier DesiCart with Static Dissipative PVC desiccator mounted in a non-corroding polyethylene cart | 4002-51B displayed Plastic Desicart This DesiCart houses a sealed four-chamber desiccator storage chamber, which maintains clean, dry storage conditions during transport, installed in a non-corroding, high-density polyethylene cart with a solid top.

This Desicart is a four chamber, two tier mobile Acrylic desiccator with a Stainless Steel and ABS plastic frame. | 4002-50B displayed Polyethylene Frame Acrylic Desicart The DesiCart houses a sealed desiccator storage chamber, which maintains clean, dry storage conditions during transport. High-Density Polyethylene DesiCarts provides excellent chemical resistance.

Shown is a custom mobile desiccator for stacking bins with chamber dimensions 46"W x 30"D x 24"H | 1001-41A displayed Extra-Large DesiCart Custom Sizes Are No Problem. Desicarts can be customized to fit your application.

Features & Benefits

DesiCart Low-RH Cart with Stainless Steel Frame

DesiCart Mobile Desiccator

This DesiCart houses a sealed two-chamber desiccator storage chamber, which maintains clean, dry storage conditions during transport, installed in a stainless steel cart with a solid stainless steel top.

Large Capacity Desicart

Custom sizes available to maintain clean, dry storage conditions of bulky items during transport.

Available Stainless Steel Shelves and Trays

Adjustable, non-contaminating shelves and trays slide on stainless steel racks, allowing easy parts access (one perforated shelf included)

Ergonomic LiftLatches

Lifting latch mechanism minimizes stress on wrists and desiccator hinges; non-rotary motion generates no particles inside the storage area (optional locking model shown)
