A - Lab Circulator Maximum Temperature
(back to chart)

Laboratory circulators and chillers include heating systems to precisely control the temperature of the water, buffer, or bath fluid.

What is the Average Lab Circulator Peak Temperature?

Lab circulators commonly heat fluid to 150°C.

Julabo’s PRESTO circulators can achieve temperature set points up to 250°C. Common applications for heating circulators include food stability testing, medical device quality analysis, and forced aging studies.

B - Lab Chiller Minimum Temperature
(back to chart)

What Lab Chiller Applications and Uses Are Most Common?

Applications for lab chillers include cell freezing, blood banking, and pour point determination of petroleum products.

What is the Lowest Achievable Lab Chiller Temperature?

Laboratory chillers, or refrigerated circulators, include cooling coils to chill bath fluid or lab-grade water. Lab chillers commonly cool fluid down to -20°C.

Julabo’s PRESTO circulators can maintain temperatures down to -80°C.

C - Lab Circulator Capacity
(back to chart)

Lab circulator capacity refers to the volume of liquid safely stored and processed by the system.

Lab Benchtop Chiller Capacity

Julabo’s Cryo-Compact chillers are low-throughput benchtop chiller systems that accommodate fluid volumes under 10 liters.

Free Standing Lab Circulator Capacity

Julabo’s FL Series circulators are high-throughput, free-standing systems that accommodate fluid volumes up to 50 liters.

D - Voltage
(back to chart)

120-volt connections are suitable for standard laboratory power outlets in the United States, Canada, Mexico, and South America.

208-volt or 240-volt connections, common in Mainland Europe and throughout Asia, require less current (amperage) and smaller conductors than equipment designed to operate at 120-volt.

E - Lab Circulator Configuration
(back to chart)

E1 - Immersion Circulator

Immersion circulators, like Julabo’s CORIO C Series, are placed within external water baths to mix and precisely control the temperature of the bath fluid. Immersion circulators are more cost-effective than benchtop circulators and more flexible: one immersion circulator can control multiple water baths within a single lab, given the baths aren’t operated simultaneously. However, immersion circulators cannot achieve the flow rates and temperature ranges of a benchtop circulator.

E2 - Open Bath Heating Circulators

Open bath circulators, like Julabo’s CORIO CD Series, include an integral, exposed water bath regulated by a digital controller. Open bath circulators provide easier sample access than enclosed bath circulators but may be prone to heat loss or larger temperature fluctuations. Common applications include temperature control of measurement cells, heating glassware, and material testing.

CORIO™ CD Refrigerated/Heating Circulators by Julabo

CORIO™ CD Heating Circulators by Julabo

E3 - Recirculating Chiller

Recirculating chillers contain enclosed water baths, cooling and/or heating coils, and digital control systems. Recirculating chillers include pump systems to deliver fluid to external equipment, such as wet processing stations, water-jacketed incubators, photometers, and refractometers. More expensive than immersion or open bath circulators, recirculating chillers provide large bath capacities, higher flow rates, broader temperature ranges and tighter set point tolerances.

F - Lab Bath Tank Material
(back to chart)

F1 - Polycarbonate Lab Bath

Transparent polycarbonate baths are more cost-effective and provide better sample visualization than stainless steel baths. However, polycarbonate baths support limited temperature ranges, typically between -20°C and 100°C.

F2 - Stainless Steel Lab Bath

Stainless steel baths help maintain aseptic conditions, resist acids and solvents, and support broader temperature ranges than polycarbonate baths.

G - Lab Circulator Power and Wattage
(back to chart)

Lab circulator power, listed in Watts (W), corresponds to the heat load capacity of the system.

Heat energy removed or applied to the fluid drives the maintainable temperature range of the system. Common lab circulators feature heat loads between 250 and 2,000 Watts.

Julabo’s PRESTO circulators include heat loads up to 2,700 Watts and, thus, industry-leading temperature ranges (-80°C - 250°C).

Where Can I Buy Lab Circulators and Chillers Online?

Laboratory-Equipment.com is a specialty division of Terra Universal. For nearly 40 years, Terra Universal has served the life science, pharmaceutical, biotechnology, and medical device markets. Customers appreciate a worldwide network of reps, factory-direct support, and ready-to-ship items available from Terra's on-shore manufacturing and warehouse facilities in Fullerton, California.

Shop lab chillers and circulators online for a wide variety of pharmaceutical, laboratory, life science research, and analytical environments. Terra specialists are able to provide support and expertise among many applications including life science research, drug discovery, material testing, wafer production, and wet chemistry.

U.S. Customer Service
Email: [email protected]
Phone: (714) 578-6016

Contact a Laboratory-equipment.com specialist through web chat, email, or phone for pricing or a same-day quote.

A - Vortexer Format - Single-Tube, Multi-Tube, Microplate Vortexers
(back to chart)

A1 - Single-Tube Vortexers

Single-tube vortexers, such as Benchmark Scientific’s Vornado Mixer, include touch-activated cups designed to accommodate sample tubes up to 50 ml in size. The cup head is sealed to prevent accidental spills from entering the housing and damaging the vortex shaft or motor.

A2 - Multi-Tube Vortexers

Multi-tube vortexers, such as Benchmark Scientific’s BenchMixer XL, include a 7” x 12” platform designed to accommodate a variety of different sample tube racks for high-volume mixing. Interchangeable tube racks are designed to house 50 x 2.0 ml micro-tubes, 15 x 50 ml culture tubes, or 3 x 96-well microplates. Multi-tube vortexers include precise motor balancing to minimize vibrations and ensure accurate, reproducible speeds across the platform.

A3 - Microplate Vortexers

Microplate vortexers, such as Benchmark Scientific’s Incu-Mixer MP, include a pre-installed plate deck capable of accommodating up to 4 microplates. The Incu-Mixer MP features a heated lid to prevent sample condensation during mixing runs. As opposed to single-tube vortexers, which can maintain mixing speeds up to 3,400 revolutions per minute (rpm), microplate vortexers, given the size of the plate deck, maintain lower speeds (up to 1,200 rpm).

B - Maximum Vortexer Shaking Speed
(back to chart)

Standard laboratory vortexers maintain shaking speeds between 100 rpm and 3,000 rpm, but specialty vortex mixers can achieve shaking speeds up to 3,400 rpm. As the force produced by the electronic drive shaft is dispersed among the samples placed on the vortexer, single-tube vortexers are capable of maintaining higher shaking speeds than multi-tube or microplate vortexers, which house multiple samples within plate decks or sample racks. Although most laboratory vortexers feature controllers capable of adjusting shaking speeds, certain vortex mixers are designed to shake at a fixed speed.

C - Digital vs Analog Vortexer Controller
(back to chart)

C1 - Analog Vortexer

Benchmark Scientific’s BenchMixers feature analog controllers with on/off switches, speed control dials, and touch-start/manual-start toggles.

C2 - Digital Vortexer

Benchmark Scientific’s Multi-Therm mixers feature digital controllers with speed adjustment, temperature control, run timers, pulse duration control, and stored, user-defined programs.

D - Vortexer Voltage
(back to chart)

120-volt connections are suitable for standard laboratory power outlets in the United States, Canada, Mexico and South America. 240-volt connections, common in Mainland Europe and throughout Asia, require less current (amperage) and smaller conductors than equipment designed to operate at 120-volt.

E - Special Vortexer Features
(back to chart)

E1 - Incubated Vortexer

Benchmark Scientific’s Incu-Mixer MP models include a heating coil to maintain temperatures up to 70°C for cell culture sample mixing.

E2 - Refrigerated Vortexer

Refrigerated vortexers, like Benchmark Scientific’s Multi-Therm, include a cooling coil to maintain temperatures down to -20°C for mixing of sensitive samples. A built-in temperature safety sensor alerts the user when conditions fall outside of setpoint.

E3 - European Vortexer Power Plug

Certain 240-volt vortexers include EU-approved or Schuko plugs for installation into laboratories located in Europe or Asia.
