Select Product




Collector Temperature



Manufacturer SKU

Terra Part #PriceShips in
240 V12LStainless SteelConsole-50°CNoneFreeZone701211010 6923-70A-220 73330 $17,85318-22 Days2
240 V12LStainless SteelConsole-50°CPurge ValveFreeZone701211110 6923-71A-220 73331 $19,06818-22 Days3
240 V12LStainless SteelConsole-50°CPurge Valve/Mini ChamberFreeZone701211210 6923-72A-220 73332 $21,14118-22 Days4
240 V12LStainless SteelConsole-50°CPurge Valve/Tray DryerFreeZone701221110 6923-76A-220 73348 $45,72618-22 Days5
240 V12LStainless SteelConsole-50°CStoppering Tray DryerFreeZone701221010 6923-75A-220 73347 $44,49618-22 Days6
240 V12LStainless SteelConsole-50°CTray Dryer/PTFE CollectorFreeZone701222010 6923-77A-220 73349 $45,80118-22 Days7
240 V12LStainless SteelConsole-84°CPurge ValveFreeZone711211110 6923-81A-220 73440 $22,47630-34 Days8
240 V12LStainless SteelConsole-84°CPurge Valve/Mini ChamberFreeZone711211210 6923-82A-220 73441 $24,55430-34 Days9
240 V12LPTFEConsole-50°CPurge Valve/PTFE CollectorFreeZone701212110 6923-73A-220 73333 $20,34318-22 Days10
240 V12LPTFEConsole-50°CPurge Valve/Mini Chamber/PTFE CollectorFreeZone701212210 6923-74A-220 73345 $22,42018-22 Days11
240 V12LPTFEConsole-50°CPurge Valve/Tray Dryer/PTFE CollectorFreeZone701222110 6923-78A-220 73350 $47,03518-22 Days12
240 V12LPTFEConsole-84°CPurge Valve/PTFE CollectorFreeZone711212110 6923-83A-220 73442 $23,76630-34 Days13
240 V12LPTFEConsole-84°CPurge Valve/Mini Chamber/PTFE CollectorFreeZone711212210 6923-84A-220 73443 $25,84030-34 Days14
240 V12LPTFEConsole-84°CPTFE CollectorFreeZone711212010 6923-85A-220 73444 $22,55530-34 Days15
240 V12LStainless SteelConsole-84°CFreeZone711211010 6923-80A-220 73471 $21,26930-34 Days16
Ice Holding Capacity
Collector Temperature
Manufacturer SKU
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product: Terra will quote.
Custom-configured product: Terra will quote.
Select a product line for product summary

Product Details

  • FreeZone 12-Liter Console Freeze Dryers by Labconco in -50C and -84C collector cooling temperatures for aqueous and low eutectic point samples
  • Console with front viewing window, inner chamber space for a vacuum pump and space for a large tray dryer
  • Features: large touch screen display, data logging, temperature sensors, manual or programmed tray dryers shelf temperature control, end point detection, USB port and Ethernet connection, vacuum break valve and patented moisture sensor and upright stainless steel collector coil
  • Includes Stoppering Tray Dryer (select models)
  • Required accessories: vacuum pump, drying chambers and freeze dry glasswares
  • Material: stainless steel collector coil and glacier white, powder-coated steel exterior
  • Removes 6/5L to 8L of water in 24 hours (depends on model)
  • Collector temperature: -50° C (-58° F) or -84° C (-119° F)
  • Ice Holding Capacity: 12 liter
  • ¾" thick collector lid with neoprene gaskets
  • Touchscreen: 5” full color Lyo-Works touch screen display provides convenient programming and useful insights
  • Program storage: 30 with up to 16 steps each
  • Available options: purge valve and mini vacuum drying chamber

  • FreeZone 12 Liter -84C Console Freeze Dryer by Labconco FreeZone 12 Liter -84C Console Freeze Dryer by Labconco
  • Labconco FreeZone 6L -84C Console Freeze Dryer with Stoppering Tray Labconco FreeZone 12L -84C Console Freeze Dryer with Stoppering Tray
  • FreeZone 12 Liter -50C Console Freeze Dryer by Labconco FreeZone -50C Console Freeze Dryer by Labconco
  • Labconco FreeZone 6L -84C Console Freeze Dryer with Stoppering Tray Labconco FreeZone 6L -84C Console Freeze Dryer with Stoppering Tray

Features & Benefits

Features & Benefits

FreeZone 12L Features

Additional Features

  • 3” diameter port (for connecting drying accessories)
  • Displays collector temperature, vacuum level, and optional End-Zone™ end point detection system in real time
  • Modes: Collector cool-down (start-up) and vacuum pull-down (automatic or manual)
  • Operating mode (standby or run)
  • Settings: multi-language, time, time zone, temperature (° C or ° F), and vacuum (mBar, Torr, or Pa)
  • Vacuum set point, alerts, diagnostic tests, user manual, defrost control, and optional drying accessory parameters
  • Data logging storage and display: table or chart format exportable via USB or Ethernet
  • Programmable alerts can be sent via Ethernet connection to user-entered email addresses.
  • Display settings: brightness, touch sounds (on/off), and screen time out in minutes (on/off)
  • Maintenance alert settings include vacuum pump oil change, refrigeration cleaning, total operating hours and line voltage offset
  • Level-specific security lock-out prevents changes to programs and other system parameters
  • Hot gas defrost with auto shut off at +65° C (+149° F)
  • On/standby switch
  • Moisture sensor prevents refrigeration or vacuum start-up when moisture is detected in the drain line
  • USB port (side-mounted) and Ethernet connection (rear-mounted)
  • Side-mounted, quick-disconnect drain hose fitting and lanyard with hose connector
  • Rear-mounted electrical receptacle for vacuum pump connection
  • Includes: 18", 1/4" ID silicone tubing and clamp, 3-wire electrical cord with plug
  • 3/4" OD vacuum connection, 50" of 3/4" ID vacuum hose and two clamps
  • Vacuum control valve maintains vacuum level set point
  • Vacuum break valve bleeds air into the system in event of power outage
-50°C Collector Temperature
  • For aqueous samples
  • Single 1 hp HCFC/CFC-free refrigeration system
  • Removes over 8 liters of water in 24 hours
  • Available Options: Purge Valve and Mini Chamber
-84°C Collector Temperature
  • For samples with low eutectic points including acetonitrile
  • Two 3/4 hp HCFC/CFC-free refrigeration system
  • Removes 6.5 liters of water in 24 hours
  • Available Options: Purge Valve and Mini Chambe
-105°C Collector Temperature
  • For samples with very low eutectic points including acetonitrile and diluted methanol or ethanol
  • Two 1/2 hp HCFC/CFC-free refrigeration systems
  • Removes 2.5 liters of water in 24 hours

Catalog of CE-Marked Products

Terra offers over 1,700 CE-marked products configured for international voltage requirements

Available Accessories

Popular Accessories

For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Labconco Rotary Vane Vacuum Pump for FreeZone
    Compatible with Labconco FreeZone Freeze Dryers, CentriVap Concentrators, and Precise or Protector glove boxes requiring vacuum service.
  • Drying Chamber, 12-port, for FreeZone systems
  • FreeZone Freeze Dry Glasswares by Labconco
    Clear Fast-Freeze Flasks by Labconco, compatible with FreeZone Freeze Dryers, are available in a variety of volume capacities; glass flasks withstand temperatures up to 490º C and include a rubber top, a glass bottom and filter paper.
