3031-42
Terra Part # 3031-42
$4,028
Usually ships in 10-16 business days

Want it faster ? Read about FasTrak

Ships Free Free shipping in contiguous USA
Terra Part # 3031-42
61350
$4,028
Usually ships in 10-16 business days

Want it faster ? Read about FasTrak

Ships Free Free shipping in contiguous USA
Product Details
  • Includes:
  • Array Plate Multi-Well
  • Hybridization Station, 110V or 220V
  • Alloy block instrument cover
  • Voltage appropriate power cord
  • Replacement fuses (2 each)
  • Replacement instrument feet (4 each)
  • Allen wrench for block removal
  • Temperature range: ambient to 100°C
  • Timer range: 1 min to 100 hours
  • Mixing speed: 300-1,500 RPM
  • Mixing amplitude of microwell samples: 3 mm
  • Temperature control accuracy: ±0.5°C
  • Display accuracy: ±0.5°C
  • Temperature uniformity ±0.5°C
  • Heating time from 20°C to 100°C: 10 min
  • Cooling time from 100° to 20°C: 10 min
  • Dimensions: 10.4"W x 12.8"D x 6.7"H (325 x 265 x 170 mm)
  • Net weight: 18.7 lbs.  (8.5 kg)
  • Power requirements: 120 volts at 60Hz and 150W

  • Compatible with microarray microplate hardware AHC4X8S, AHC4X8L AHC4X16 and AHC4X24
  • Model has 1 microarray per well; 24 microarrays per slide (4 slides per plate); 96 microarray total
  • Microcomputer controls timer, heating and cooling and mixing
  • 3-color digital display
  • Versatile alloy block accommodates microplates and single tubes
  • Applications: Hybridizes/incubates DNA, protein, carbohydrate and peptide microarrays; also used for cell studies, transcription, immunoprecipitation, enzyme kinetics, and more

Equipment Type: Hybridization Station

Slide Capacity: 96 Slides

Complete Hybridization Station: Yes

Chiller Bath: No

Manufacturer SKU: MMHS110V

Unit of Measure: EA

Weight, Product: 19 Lbs

Dimensions, Product: 11"W x 13"D x 7"H

Weight, Shipping: 35 Lbs

Dimensions, Shipping: 15"W x 15"D x 12"H

Package Type: Box

Features and Benefits

Learn More: Single and Multi-Plate Models

More Information

Model #MMHS110V #MMHS2 #MMHS4
Capacity Single-Plate Capacity 2-Plate Capacity 4-Plate Capacity
Simultaneous reactions up to 96 microarrays up to 192 microarrays up to 384 microarrays
Mixing speed 300 to 1,500 rpm 300 to 1,200 rpm
Temperature range ambient to 100°C heating ambient to 60°C heating
Timer range 1 minute to 100 hours
Mixing amplitude of micro-well samples 3 mm
Temperature control accuracy ±0.5°C
Display accuracy ±0.5°C
Temperature uniformity ±0.5°C
Heating time 20°C to 100°C: 10 minutes 25°C to 37°C: 10 minutes
Cooling time 100° to 20°C: 10 minutes 37°C to 25°C: 5 minutes
Dimensions
(W x D x H)
10 x 13 x 7 in.
(270 x 330 x 170 mm)
10 x 11 x 5 in.
(260 x 270 x 130 mm)
15 x 15 x 6 in.
(381 x 381 x 140 mm)
Net weight 18.7 lbs. (8.5 kg) 13.4 lbs. (6.1 kg) 19.4 lbs. (8.8 kg)
Compatible well configurations AHC4x8L and AHC4x24 well configurations
Power requirements 110 – 240V AC at 50/60Hz and 150W 110-240V AC at 50/60Hz and 40W 110-240V AC at 50/60Hz and 50W
Includes
  • Array Plate Multi-Well
  • Hybridization Station, 110V
  • Alloy block instrument cover
  • Voltage appropriate power cord
  • Replacement fuses (2 each)
  • Replacement instrument feet (4 each)
  • Allen wrench for block removal
Accelerates Hybridization Rates by Approximately 10-Fold
Figure 1-A. Hybridized for 30 minutes at 42° in 30 µl under a glass cover slip
Figure 1-B. Hybridized for 30 minutes in 200 µl at 500 rpm using an Array Plate Hybridization Station. Figure 1-B shows a 10-fold increase in signal compared to figure 1-A. Even with a 6.7-fold greater probe dilution, the Array Plate produced a stronger signal compared to static cover slip hybridization reactions. Note: Microarrays were spun dry for 3 seconds using the Microarray High-Speed Centrifuge and scanned on an Arrayit InnoScan® 710AL Two-Color High-Speed Fluorescence Scanner
Figure 2. The Plate Hybridization Station accommodates various cassettes for fast and effective microarray hybridization reactions. Gaskets can be modified to various formats. Cassettes are sealed with a microplate foil seal to eliminate sample evaporation during hybridization process.
Figure 3. Multi-Well Hybridization Stations accept various interchangeable block tubes for holding tubes, plates, chambers and cassettes.
Figure 4. This display diagram shows the various features of Microarray Multi-Well Microarray Hybridization Stations.
