Select Product

Material

Configuration

Terra Part #PriceShips in
PolypropyleneSingle Side Access 1530-50A 66727 $5,2051-3 Days2
In stock soon
FM4910 PolypropyleneDual Side Access 1530-51B-FM 68635 $8,562.....3
FM4910 PolypropyleneSingle Side Access 1530-50A-FM 68634 $10,6451-3 Days4
In stock soon
Material
Configuration
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product: Terra will quote.
Custom-configured product: Terra will quote.
Select a product line for product summary

Product Details

  • 3-sided enclosure minimizes chemical splashes, eases personnel entry and exit
  • Design includes PVC plumbing that connects to in-house water supply by means of 1.25" pipe fitting
  • Sloping bottom feeds water into 2.5" diameter drain line
  • Polypropylene sides and bottom resist most common acids and corrosives
  • Immediate-response operation handles are easy to activate
  • Reliable operation with a fully enclosed design that enhances safety both inside and outside the shower area
  • By shielding the shower on three sides, the polypropylene enclosure minimizes the chance of the water spraying and harmful chemical splashes, affecting parts or personnel outside the shower
  • Vinyl strip curtain on the front is easily parted for quick entry into the enclosure.
  • This design eliminates the tricky task of fumbling with a door latch in an emergency.
  • Standard overhead nozzle height is 78" (1981 mm) off the shower floor; the eye rinse are positioned 42" (1067 mm) off the floor
  • Shower comes complete with PVC plumbing that connects to your in-house water supply by means of a 1.25" (32 mm) ID pipe fitting
  • The sloping bottom feeds into a 2.5" (64 mm) drain line
  • Provides full-body shower and eye wash while protecting lab against water and chemical splashes
  • Polypropylene enclosure resists most lab acids and corrosives
  • Welded 0.5" (13 mm) polypropylene enclosure (for chemical-resistance) with 40 mil transparent vinyl strip curtain on front, 8"-wide strips with 2" overlap
  • 10"-diameter ABS plastic overhead nozzle, 5.75"-diameter flow pattern, with 304 stainless steel pull handle
  • Zinc-plated eye rinsers, 8" center-to-center in 12"-diameter bowl, mounted 42" off floor, with zinc-plated push handle
  • Easy-parting transparent vinyl curtain allows fast, convenient access while shielding the external environment
  • Immediate-response operation handles are easy to activate
  • Pass-Through design allows access from either side; perfect for hallways or walls connecting labs
  • FM 4910 polypropylene available (call for quote)
  • Requires 1.25" ID (male) water feed line connection and 2.5" ID (male) drain line

Lab Safety Products

  • Enclosed Safety Shower - Dual Access Diagram Enclosed Safety Shower - Dual Access Diagram
