Select Product
Voltage

Type

Application

Air Flow

Final Filter Type

Manufacturer SKU

Terra Part # Price Ships in
120 V Wheeled Trolley Cleanroom Use ISO 4 87 ULPA 1790150 1764-00 9021 $1,570 12-18 Days 2
Ships Free In stock soon
220 V Wheeled Trolley Cleanroom Use ISO 4 87 ULPA 1790152 1764-00-220 36523 $1,656 12-18 Days 3
Ships Free
Voltage
Type
Application
Certified ISO Grade Design
Air Flow
Final Filter Type
Manufacturer SKU
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Terra by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Terra by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • Available ISO Rated Designs: ISO 4, ISO 5, ISO 6, ISO 7, ISO 8
  • 9.25-liter bag and napped-cotton filter traps large particles
  • Air passes through a microfilter (rated 99.999% efficient @ 0.5 µm particles)
  • An ULPA filter completes the 4-stage filter system
  • ULPA filter is 99.999% effective for particles 0.12 microns
  • Quiet (59 dBA) at 6.5 feet, to prevent workplace disturbances
  • Vacuum meets the electrical safety standards outlined in the Williams Steiger Occupational Safety and Health Act of 1970 (OSHA)
  • Interference-suppressed for efficiency and reliability
  • Single-phase motor has thermal protection device to prevent overheating
  • Includes exhaust filter assembly, AES microfilter, two 22" stainless steel straight tubes, 3" round brush, combination 12" floor nozzle, 6'-6" (2012 mm) conductive plastic hose, detachable trolley, 30' power cord, conductive crevice nozzle, 5" utility nozzle, and five paper bags
  • Conductive plastic hose and accessories, along with grounded cord, enhances ESD safety
  • Designed for intermittent duty
  • Positive twist safety latches for added security
  • Water Lift: 102"
  • Air Flow: 87 CFM
  • Suction Power: 250 air watts
  • Tank Capacity, dry bulk: 3.25 gallons (14.3 liters)
  • Paper Bag Capacity: 2.25 gallons (9.9 liters)
  • 30 ft power cord
  • Glass fiber filter with steel casing
  • Filter surface area: 576 sq. in. (0.4 m2)

• Available ISO Rated Designs: ISO 4, ISO 5, ISO 6, ISO 7, ISO 8

• ISO Rated Design: ISO 4

Features & Benefits

Features & Benefits

Products Tailored to Your Cleanroom Environment

Provide Terra with your desired ISO Gradeâ„¢ design. We will tailor the product to meet your criteria and certify it with a report appended to your invoice. Certificate includes all the necessary information to streamline audits and facility compliance.

Protecting Personal Information

Terra is committed to ensuring that our customer’s personal information is secure. In order to prevent unauthorized access or disclosure, Terra has developed procedures to safeguard and secure information collected online and offline.

Global Customer Base

At Terra, we are committed to providing top-tier equipment to customers throughout the world. Over the past 5 years, clients in over 100 countries have purchased equipment from Terra.

Top-Tier Clients

Terra’s key customers include some of the largest research labs, production facilities and universities in the world
Available Accessories
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Exhaust Filter Assembly; Replacement Part for Vacuum Cleaner

  • Replacement Vacuum Cleaner Filter

    Replacement vacuum cleaner ULPA filter is 99.999% effective for contaminating particles 0.12 microns. Its unique four-stage filter system removes particles and dust before returning the air to the workplace.
  • Nilfisk Replacement Vacuum Cleaner Microfilter

    Made of AES polycomposite material, this Nilfisk microfilter is 99.9986% efficient @ 0.5µm particles, and lasts 500 hours.
  • Nilfisk Disposable Vacuum Paper Bags

    Just slide the plastic collar over the intake opening and the Nilfist vacuum cleaner bag is installed. When full, the bag slides back off for clean easy disposal. Capacity: 2.25 gallons (9.9 liters).
