Select Product

Door Frame

Door Panel

Operation

Opening Action

Opening Height

Opening Width

Terra Part #PriceShips in
Powder-Coated Aluminum Static-Dissipative PVC Automatic Double Bi-Parting 80" 80" 5556-10-PC 75227 $7,11410-15 Days2
Powder-Coated Aluminum Static-Dissipative PVC Automatic Double Bi-Parting 84" 60" 5556-09-PC 75226 $7,04610-15 Days3
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 34" 5556-06-LS-PC 75220 $5,83910-12 Days4
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 40" 5556-07-LS-PC 75222 $5,90510-12 Days5
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 46" 5556-08-LS-PC 75224 $5,97310-15 Days6
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 34" 5556-06-RS-PC 75221 $5,83910-12 Days7
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 40" 5556-07-RS-PC 75223 $5,90510-15 Days8
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 46" 5556-08-RS-PC 75225 $5,97310-12 Days9
Powder-Coated Aluminum Tempered Glass Automatic Double Bi-Parting 80" 60" 5556-01-PC 75214 $6,76510-15 Days10
Powder-Coated Aluminum Tempered Glass Automatic Double Bi-Parting 80" 80" 5556-04-PC 75219 $6,83410-15 Days11
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 34" 5556-02-LS-PC 75215 $5,56010-15 Days12
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 40" 5556-00-LS-PC 75212 $5,62610-15 Days13
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 46" 5556-03-LS-PC 75217 $5,69310-15 Days14
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 34" 5556-02-RS-PC 75216 $5,56010-15 Days15
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 40" 5556-00-RS-PC 75213 $5,62610-15 Days16
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 46" 5556-03-RS-PC 75218 $5,69310-15 Days17
Door Frame
Door Panel
Operation
Opening Action
Opening Height
Opening Width
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Item is in stock and ready for immediate shipping
Free shipping in contiguous USA
Custom-configured product: Terra will quote.
Custom-configured product: Terra will quote.
Select a product line for product summary

Product Details

• Door track is mounted externally to wall surface

• Well suited for retrofit construction and easy installation where a large opening is not possible for recessed door frames.

• Touchless motion door pad for hands-free operation

• Elastomeric door seals and fiberglass reinforced timing belt ensures cleanliness, durability and uniform closing

• Microprocessor controller continually monitors door position with adjustable opening and closing speed, distance and speed of braking reduces opening and time delay

• Auto reverse on obstruction; slow speed search for obstruction

• Load-bearing wheels made of cast urethane for long-lasting, smooth and trouble-free operation

• Adjustable anti-riser wheels lock each door in its overhead track

• Doors undergo life testing to a minimum of one million cycles

• Static-dissipative PVC door panels enhance static and particle control, stand up to cleaning agents, minimize obstructive sight lines and reduce claustrophobic sensation in small rooms

• Quick installation with pre-assembled header and panel sub-assemblies

• ANSI compliant

• See overall dimensions below; adequate clearance required for door opening

• Custom sizes and configurations, including swing and folding doors, available; call Terra to discuss your requirements!

Doors

  • Terra Universal BioSafe Doors Video Terra Universal BioSafe® Doors
  • Short video showing the cleanroom automatic door Cleanroom Automatic Doors
Terra Universal BioSafe Doors Video
Short video showing the cleanroom automatic door

Features & Benefits

Features and Benefits

Door Sliding Direction

Door sliding direction is easily determined while standing on the SECURE SIDE (key side) or OUTSIDE of the door.

External Mount Automatic Sliding Door Diagram

Exploded view of an externally mounted automatic sliding door.

Clean and Durable Powder Coat Finish

Terra’s signature white powder coat finish provides a high quality, durable barrier to protect against corrosion, plus a clean and attractive aesthetic. The advanced heat-fused formulation exceeds ASTM and ISO paint standards to resist chipping, scratching, fading, and wearing.

Continuous Product Improvement

At Terra, we strive to develop and produce the highest quality products for our customers to improve health, safety, performance, and yields. Our product quality is enabled by high-grade manufacturing equipment and processes, 45 years of engineering and application expertise, and our commitment to continuously improve.
