Select Product

Door Frame

Door Panel

Operation

Opening Action

Opening Height

Opening Width

Terra Part #PriceShips in
Aluminum Tempered Glass Automatic Automatic Right Sliding 84" 42" 5555-00A-RS$6,11210-12 Days
Aluminum Tempered Glass Automatic Automatic Bi-Part 84" 60" 5555-01A$7,12710-12 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Double Bi-Parting 80" 80" 5555-10B-PC$7,43810-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 40" 5555-07B-RS-PC$6,36210-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 34" 5555-06B-RS-PC$6,30310-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Right Sliding 80" 46" 5555-08B-RS-PC$6,42210-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 40" 5555-07B-LS-PC$6,36210-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 34" 5555-06B-LS-PC$6,30310-15 Days
Powder-Coated Aluminum Static-Dissipative PVC Automatic Left Sliding 80" 46" 5555-08B-LS-PC$6,42210-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Double Bi-Parting 80" 60" 5555-01B-PC$7,12710-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Double Bi-Parting 80" 80" 5555-04B-PC$7,18810-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 40" 5555-00B-RS-PC$6,11210-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 34" 5555-02B-RS-PC$6,05310-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Right Sliding 80" 46" 5555-03B-RS-PC$6,17210-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 40" 5555-00B-LS-PC$6,11210-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 34" 5555-02B-LS-PC$6,05310-15 Days
Powder-Coated Aluminum Tempered Glass Automatic Left Sliding 80" 46" 5555-03B-LS-PC$6,17210-15 Days
Door Frame
Door Panel
Operation
Opening Action
Opening Height
Opening Width
Item ordered before. Click on bagde to see the order.
Demo Available
Some ship in:
Usually Ships in:
Item is in stock and ready for immediate shipping
Free shipping in contiguous USA
Select product to see details

Product Details

Designed in the USA

• Door Frame and track are installed inside existing wall cutout/partition

• Touchless motion door pad for hands-free operation

• Well suited for room partitions or openings larger than desired door size; can be configured to include side lights for additional visibility

• Elastomeric door seals and fiberglass reinforced timing belt ensures cleanliness, durability and uniform closing

• Microprocessor controller continually monitors door position with adjustable opening and closing speed, distance and speed of braking reduces opening and time delay

• Auto reverse on obstruction; slow speed search for obstruction

• Load-bearing wheels made of cast urethane for long-lasting, smooth and trouble-free operation

• Adjustable anti-riser wheels lock each door in its overhead track

• Safety features include door breakout at 50 lbs. of pressure

• Doors undergo life testing to a minimum of one million cycles

• Static-dissipative PVC door panels enhance static and particle control, stand up to cleaning agents, minimize obstructive sight lines and reduce claustrophobic sensation in small rooms

• Quick installation with pre-assembled header and panel sub-assemblies

• ANSI compliant

• See overall dimensions below; adequate clearance required for door opening

• Custom sizes and configurations, including swing and folding doors, available; call Terra to discuss your requirements!

Doors

  • Short video showing the cleanroom automatic door Cleanroom Automatic Doors
Short video showing the cleanroom automatic door

Features & Benefits

Features and Benefits

Automatic Sliding Doors

More Information

  • Construction: Clear anodized aluminum frames are easy to clean and sterilize (other frame colors optional)
  • Position Switch: Single or Dual (optional)
  • Alarm Contacts: Optional
  • Transom: Optional
  • Threshold Configuration: Standard no-threshold design allows easy transfer of carts and other items; thresholds available on optional basis
  • Emergency Power Options: Uninterruptible Power Supply (UPS); extended operation Fly Open Box; One time operation
  • Locking options (2-Point locking standard): 3-Point Locks, Lock position indicators, Armored strikes, Electric Solenoid Lock (Fail Safe/Fail Secure), Access Control Locking with surface or recessed panic hardware
Specifications
  • Design: Bi-Part or Single Slide
  • Breakout: Sliding Panels Only
  • Jamb Dimension: 1 3/4" x 4 1/2" 1 3/4" x 6"
  • Finish: Clear Special Finish Available
  • Panels: Static-dissipative PVC
  • Locking: Single Point Bottom Rail Deadlock(s) Electric Locking
  • Controls: Touchless or biometric keypad Biometric or card key reader
  • Sensors: 2 SU-100s / Stanguard 2 Wizards
  • Drive System: ¼ HP DC gear driven motor, twin ¼ HP DC gear driven motors (optional)
  • Material: Door Panel options (special quote): tempered glass, polycarbonate
  • Compliance: UL, cUL, ANSI A156.10, UBC, BOCA, ICBO, NFPA 101
  • STANLEY SU-100 MOTION SENSORS: Uni-directional function reduces length of time door stays open by detecting approaching traffic; saves energy by preserving loss of heat and air conditioning
  • Stan-Guard® Threshold Sensor: Configurable Options: threshold sensor and doorway holding beam detects and holds the door open for people and objects until area is clear
  • Security Options: Security access options include card readers, biometric readers, passcode readers and overhead cameras; call Terra for more information
  • Battery Backup: Extends operation of automatic doors up to 1.5 hours in event of power outage or failure (optional)

Door Sliding Direction

Door sliding direction is easily determined while standing on the SECURE SIDE (key side) or OUTSIDE of the door.
