Select Product

Door Frame

Door Panel

Operation

Opening Action

Opening Width

Window Size

Terra Part #PriceShips in
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticDouble Swing81"72"Partial View 1999-94 75110 $9,05810-15 Days2
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticDouble Swing81"72"Full View 1999-95 75321 $9,61910-15 Days3
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticSingle Right Swing81"36"Partial View 1999-89-R 75109 $5,26810-15 Days4
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticSingle Right Swing81"36"Full View 1999-96-R 75323 $5,82910-15 Days5
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticSingle Left Swing81"36"Partial View 1999-89-L 75108 $5,26810-15 Days6
CleanSeam™ 316L Stainless SteelTempered GlassAutomaticSingle Left Swing81"36"Full View 1999-96-L 75322 $5,82910-15 Days7
Door Frame
Door Panel
Operation
Opening Action
Opening Height
Opening Width
Window Size
Item ordered before. Click on bagde to see the order.
Demo Available
Some ship in:
Usually Ships in:
Item is in stock and ready for immediate shipping
Free shipping in contiguous USA
Custom-configured product: Terra will quote.
Custom-configured product: Terra will quote.
Select a product line for product summary

Product Details

• Hands-free operation with motion sensor and sensor pad (included)

• Design free of cracks and crevices where microbes can colonize

• Stainless steel resists disinfectants, won't produce contaminants during sterilization

• Rounded corners for easy wipe downs

• Designed for life science applications, such as personal medicine and biomedicine

• Pre-hung automatic swing doors for conventional cleanroom construction

• Compact module; 65% smaller than other manufacturer models

• Whisper-quiet operation

• Models designed for single and double swing doors

• Pull side track mount

• Continuous-seam eliminates cracks and crevices for easy cleaning and sterilization

• Advanced power assist during opening cycle; minimal effort when operated manually

• Precise controlled opening and closing speeds promote safety

• Blow-open feature for smoke ventilation (per NFPA 92B)

• Onboard power supply eliminates need for secondary power supply

• Twelve Programmable Options satisfy simple and complex door installations

• ADA compliant; ideal for persons carrying objects or pushing carts

• Available pre-installed on framed cleanroom doors (aluminum or stainless steel)

• Automatic doors are shipped pre-hung on specified frame, ready to install, and come with a concealed pneumatic closing mechanism and door stop

• Intended for use in positive or negative pressure cleanrooms where air movement is acceptable. Doors are not hermetically sealed and not intended for spaces mitigating operator exposure to biohazards, chemicals, or nauseating odors.

• Door assembly is leak-rated by UL for tight seal to maintain cleanroom pressure gradients

Doors

  • Short video of the automatic door Cleanroom Automatic Door
  • Video showing the automatic cleanroom doors Automatic Cleanroom Door
Short video of the automatic door
Video showing the automatic cleanroom doors

Features & Benefits

Features and Benefits

Door Swing Direction

Door swing direction is easily determined while standing on the SECURE SIDE (key side) or OUTSIDE of the door.

Continuous-Seam Welds

Smooth surfaces and corners are easy to clean, ideal for critical bio/pharmaceutical facilities.

Flush-Mount Dual Pane Windows

Flush mount dual-pane window design simplifies cleaning.

Smooth Corners and Surfaces

Continuous-seam welds on all sides of door minimize surface crevices for easy cleaning.

BioSafe®: Terra's Ultimate Cleanliness Rating

Terra's BioSafe products are designed for life science applications: no gaps and crevices where microbes can colonize, rounded corners for easy disinfection, won't produce contaminants during sterilization, and exceed cGMP, IEST, ASTM and ISO 14644-1 requirements.

Easy to Clean Door

Cleanseam smooth-welded edges eliminate hard-to-clean crevices where bacteria could accumulate, leaving a sleek, BioSafe stainless steel surface.

Easy to Clean Flush-Mount Window

BioSafe windows forego shoddy spot-welding in favor of dual-pane glass installed flush on steel for a continuously smooth surface.

Easy to Clean Door Frame

Terra Universal's BioSafe door frames have continuous welded seams that eliminate crevices, and gasket seal for extra cleanroom security.

Automatic Door Bottom Gasket for Cleanroom Doors

The automatic door bottom is equipped with a fully concealed drop-down gasket that seals the bottom gap when the door closes so the room can effectively maintain pressure difference.
