• Temperature Range: -30 to 150°C
• Tank Capacity: 7.5 L
• Refrigerated: Yes
• Heated: Yes
• Power: 1000W
• Family: Corio CD Refreigerated
• Tank material: Stainless Steel
• Manufacturer SKU: 9012704
• Unit of Measure: EA
| Model | CORIO CD-200F | CORIO CD-201F | CORIO CD-300F | CORIO CD-600F |
|---|---|---|---|---|
| Working Temp. | -20°C to +150°C | -20°C to +150°C | -25°C to +150°C | -35°C to +150°C |
| Dimensions (W x D x H) | 9.1” x 15.4” x 25.6” (230 x 390 x 650 mm) | 17.4” x 16.2” x 17.4” (440 x 410 x 440 mm) | 9.5” x 16.6” x 26” (240 x 420 x 660 mm) | 13” x 18.5” x 27.2” (330 x 470 x 690 mm) |
| Bath Tank Opening | 5.1” x 5.9” | 5.1” x 5.9” | 8.6” x 5.9” | 8.6” x 5.9” |
| Filling Volume | 3 to 4 liters | 3 to 4 liters | 5 to 7.5 liters | 5 to 7.5 liters |
| Product Weight | 57.4 lbs. (26 kg) | 55.2 lbs. (25 kg) | 61.8 lbs. (28kg) | 79.4 lbs. (36 kg) |
| Cooling Capacity | 0.22kW @ +20°C 0.17kW @ 0°C 0.06kW @ -20°C | 0.2kW @ +20°C 0.16kW @ 0°C 0.06kW @ -20°C | 0.31kW @ +20°C 0.28kW @ 0°C 0.11kW @ -20°C | 0.6kw @ +20°C 0.53kw @ 0°C 0.22kw @ -20°C |
| Barbed fittings | Diameter 8/12 |
|---|---|
| Pump Capacity | 15 L/Min |
| Pump Capacity Flow | 5.08 psi |
| Refrigerant | R134a |
| Operating Temperature (Ambient) | 5°C to 40°C |
| Temperature Stability | ±0.03 |
| Setting/Display Resolution | 0.1°C |
| Heating Capacity kW | 1 |
| Pump Connections | M16x1 |
