Wafer Storage Desiccators,Wafer Storage Desiccators

Desiccator; Wafer Box, for 200 mm Wafers, Clear Acrylic, 5 Chambers, 27.25" W x 25" D x 61" H

• Number of Chambers: 5

• Chamber Dimensions: 25.25" W x 22.5" D x 11.75" H

• Opening Dimensions: 25.625" W x 10.875" H

• Material: Clear Acrylic

• Wafer Size: 200 mm

• Marks & Listings: CE, UL, ULC

• Dimensions, Product: 27.25" W x 25" D x 61" H

• Dimensions, Shipping: 66" W x 30" D x 28" H

• Weight, Product: 100 lb

• Weight, Shipping: 224 lb

• Package Type: Crate

• Unit of Measure: EA

Read more
CE Mark Logo ULus Logo
Terra Part #: 9130-21B
Manufactured By: Terra Universal
Warranty: 1 year parts, 90 days labor
Print
Need Help?

(714) 578-6100

Mon - Fri, 5:30 AM - 5:30 PM, PST

Chat

Want a quote quickly ?

Submit a QuickQuote request
Terra Part # 9130-21B
$4,230
Usually ships in 15-19 business days

Want it faster ? Read about FasTrak

Details & Specs
Manuals & Resources
Related Products

• Chambers Per Tier: 1

• Wafer Size: 200mm

• Capacity: 20 (based on box size of 10.75" x 10.94" x 9.88" (273 x 278 x 249 mm) with 4 boxes per chamber)

• Chamber size designed to accommodate wafers with optimum air flow and humidity

• Chrome-plated LiftLatches™ included; Locking Liftlatches also available - specify Locking Liftlatch for each chamber when the cabinet is ordered

• Upgrade to all-stainless steel LiftLatches™ to minimize scratching, corrosion and contamination resulting over time with chrome-plated latches; specify when ordering

• Powder-coated Steel Stand can be ordered separately

• CAUTION: Acrylic is damaged by alcohol and many other cleaning agents. Use only water and mild detergent

Show more

• Number of Chambers: 5

• Chamber Dimensions: 25.25" W x 22.5" D x 11.75" H

• Opening Dimensions: 25.625" W x 10.875" H

• Material: Clear Acrylic

• Wafer Size: 200 mm

• Marks & Listings: CE, UL, ULC

• Dimensions, Product: 27.25" W x 25" D x 61" H

• Dimensions, Shipping: 66" W x 30" D x 28" H

• Weight, Product: 100 lb

• Weight, Shipping: 224 lb

• Package Type: Crate

• Unit of Measure: EA

Show more

Manuals & Resources

Products similar to this one
  1. High-volume storage unit hold a full vacuum for 24 hours at room temperature (accessories not included) | 3308-11 displayed
    $301
    Usually Ships in 15 - 25 days
    Desiccator; Polycarbonate, 22" W x 22" D x 18" H, Secador Techni-Dome 360
Other products you may find relevant
  1. Closed-cell PVC foam gasketing withstands dry environment inside desiccators | 1100-26 displayed
    $37
    Usually Ships in 1 - 3 days
    Gasketing, Desiccator Door; 25 ft. long
  2. Shown on a reference grid of 1-inch (25mm) squares | 1100-27 displayed
    $67
    Usually Ships in 1 - 3 days
    Gasketing, Desiccator Door; 50 ft. long
  3. Shown with optional SS wire ssupports. | 3607-03 displayed
    $101
    Usually Ships in 1 - 3 days
    Stainless Steel Rack; for Tape and Reel Desiccator, 23.5''W x 7.75"D x 0.75''H
  4. Accuracy: 5% @ 25C from 10% to 90%RH | 5401-17 displayed
    $109
    Usually Ships in 1 - 3 days
    Psychrometer; Digital, Handheld, AAA Batteries
  5. Sealed outer shell is fabricated of static-dissipative PVC for additional ESD protection | 2650-99 displayed
    $5,451
    Usually Ships in 20 - 24 days
    Mobile Desiccator Cabinet; 1 Chamber, Static Dissipative PVC, 23.75" W x 28.875" D x 60.25" H ID
  6. Stores 16,382 temperature readings and 16,382 relative humidity measurements. | 9500-10 displayed
    $240
    Usually Ships in 1 - 3 days
    Data Logger; Relative Humidity/Temperature
  7. Qualification Documentation (IQ/OQ) for Terra Universal System
    Request Quote
    Usually Ships in 5 - 5 days
    Qualification Documentation (IQ/OQ) for Terra Universal System
  8. Digital thermometer with humidity indicator for cleanroom application. | 5401-34 displayed
    $209
    Usually Ships in 1 - 3 days
    Thermo-Hygrometer; Wireless, LCD, 8-Channel, with Remote Sensor
  9. The Portable CleanBooth™ wheels into position above a workbench or equipment to provide an ISO 5-compliant flow of HEPA-filtered air (flexible side panels and f | 1870-03A displayed
    From
    $2,572
    Some ship in 1 - 3 days
    Portable CleanBooth™; Vertical Laminar Flow
  10. DesiCart, Low Humidity Transport Carts features high-density polyethylene frame, steel rails, and a four chamber acrylic desiccator | 4002-50B displayed
    From
    $2,510
    Some ship in 23 - 31 days
    DesiCart™ Low-Humidity Transport Carts
  11. A convenient, contamination free, economical carrying container for moisture-sensitive devices | 9302-23B displayed
    From
    $455
    Some ship in 1 - 3 days
    Portable Desiccator Dry Boxes
  12. Sure-Grip EX safety can storage cabinets protect workers, reduce fire risks, and improve productivity by storing hazardous liquids in high performance | 2820-00A displayed
    From
    $532
    Some ship in 8 - 12 days
    Sure-Grip® Flammable Liquid EX Safety Can Storage Cabinets from Justrite
  13. Undercounter Flammable safety cabinets by Justrite includes dual vents with flame arresters located in the back | 1619-95 displayed
    From
    $548
    Some ship in 8 - 12 days
    Sure-Grip® EX Undercounter Flammable Safety Cabinets by Justrite
  14. Yellow Slimline safety cabinets by Justrite are fire resistant double wall, air insulated and welded steel construction | 1619-90 displayed
    From
    $587
    Some ship in 8 - 12 days
    Yellow Slimline Safety Cabinets by Justrite
  15. Sure-Grip EX deep SlimLine safety cabinets provides OSHA-, NFPA-compliant protection and containment of flammable materials | 1618-21 displayed
    From
    $938
    Some ship in 8 - 12 days
    Sure-Grip® EX Deep Slimline Safety Cabinets by Justrite
  16. Corrosive Storage by Justrite features two manual stainless steel doors with 3-point stainless steel bullet latching system | 2820-09A displayed
    From
    $629
    Some ship in 8 - 12 days
    Corrosive Storage Cabinets by Justrite
  17. Stainless steel BioSafe Cleanroom Clipboards provide non-shedding, durable, conductive surfaces, ideal for aseptic environments | 1350-00A-2 displayed
    From
    $58
    Some ship in 1 - 3 days
    BioSafe® Cleanroom Clipboards
  18. Palm-Sized Temperature/Humidity Meters available with built-in or probe sensors | 1401-17 displayed
    From
    $477
    Some ship in 10 - 16 days
    Palm-Sized Temperature/Humidity Meters
  19. PureFlow Laminar Transport Cart system provides an uninterrupted vertical laminar flow of HEPA-filtered air in the storage | 1529-64A displayed
    From
    $11,519
    Some ship in 20 - 24 days
    PureFlow™ Laminar Flow Transport Carts
  20. This all-stainless Steel Security Cabinet features a lock with fingerprint scanner for secure storage of pharmaceuticals | 1989-10 displayed
    From
    $2,262
    Some ship in 1 - 3 days
    Locking Pharmaceutical Security Cabinets
  21. Ionizing bars neutralize surface static charges, protecting sensitive materials and preventing particle buildup due to static cling
    From
    $414
    Some ship in 1 - 3 days
    Ionizing Bars
  22. This Ionizing Blow-off Gun neutralizes static surface charges and removes particles with a burst of clean air or nitrogen | 2005-55 displayed
    From
    $729
    Some ship in 1 - 3 days
    Cleanroom Ionizing Blow-Off Gun
  23. Designed with a compact and rugged enclosure, this chart recorder provides accurate record for temperature, humidity, and dew point | 4801-66 displayed
    From
    $489
    Some ship in 5 - 7 days
    Chart Recorders – Temperature, Humidity, and Dew Point
  24. Terra’s hygro-thermometer offers simultaneous display of temperature and humidity in a large LCD readout | 5401-21 displayed
    From
    $45
    Some ship in 1 - 3 days
    Hygro-Thermometers (Large Display)
  25. Curing/Drying Cabinets provide dual HEPA/carbon filtration | 6082-43A displayed
    From
    $4,012
    Some ship in 4 - 6 days
    HEPA/ULPA Filtered Curing/Drying Cabinets
  26. Nitrogen Generators provide a reliable source of clean, dry nitrogen, requiring only a compressed air source
    From
    $5,806
    Some ship in 1 - 3 days
    Nitrogen Generators
  27. Designed to provide reliable gas drying without the hassle and expense | 9082-01 displayed
    From
    $3,201
    Some ship in 1 - 3 days
    Dryex Gas Dryer
  28. Heated WhisperFlow Fan Filter Units (FFUs) provides a uniform flow of heated ULPA-filtered air for parts drying and other operations at above-ambient temperatur | 6601-24-UT displayed
    From
    $1,505
    Some ship in 10 - 14 days
    Heated Fan Filter Units
  29. Desiccator Trays, Stainless Steel
    From
    $183
    Some ship in 1 - 3 days
    Desiccator Trays, Stainless Steel
  30. Measures temperature from -40 to +212F | 3710-04A displayed
    Request Quote
    Usually Ships in 12 - 22 days
    Temperature/Relative Humidity Meter; Digital, Probe Sensor, Vaisala, Battery

Wafer Storage Desiccators

  • Desiccators: Features and Design overview
  • Leveling your Desiccator
Desiccators: Features and Design overview Terra's nitrogen-purged desiccator cabinets meet dry storage requirements as low as 1% relative humidity. Standardization simplifies component upgrade, retrofit and replacement. Terra's Smart controllers allow setpoint control and even multiplexed purging for the most critical humidity requirements.
Leveling your Desiccator Learn how to properly level your plastic or stainless steel desiccator cabinet, as well as instructions to align the doors.

Features and Benefits

Plastic Wafer Box Desiccator Cabinets

Optimal Space Efficiency

Wafer Desiccator Cabinets are designed specifically for standard 200 mm and 300 mm wafer lot boxes used in semiconductor operations; select dissipative PVC for static safety.
Automatic Relief/Bleed Valve

Automatic Relief/Bleed Valve

Terra's Automatic Relief/Bleed (RB) Valve opens up at 0.01 PSI, relieving overpressure that could damage desiccators; also works as a check valve to prevent influx of room air.
Acrylic 10 Chamber Wafer Box Desiccator Cabinet

Acrylic Wafer Box Desiccator Cabinet

Wafer Desiccators are designed specifically for standard lot boxes used for 200 mm and 300 mm wafers. Advanced construction features include plenum chamber, 304 stainless steel door frames, LiftLatches™, and one-piece front sealing panel
Static-Dissipative PVC Plating

Static-Dissipative PVC Plating

Terra's SDPVC features bonded dissipative layers that resist abrasion. SDPVC desiccators retain their surface resistivity of 106 - 108 ohms/square indefinitely (unlike spray-on coatings that can wear off after a few years), protecting your materials against ESD damage. Further, the control of static charges eliminates particle attractions, helping maintain clean surfaces.
Stainless Steel Desiccator Liftlatches

Ergonomic LiftLatches

Lifting latch mechanism minimizes stress on wrists and desiccator hinges; non-rotary motion generates no particles inside the storage area (optional locking model shown)
Desiccator Cabinet Doors and Gaskets

Reinforced Doors with Non-adhesive Gaskets

Stainless steel door frames extend desiccator life; one-piece fused gaskets are non-outgassing, will not creep or sag
Desiccator Plenum Chamber For Uniform Gas Distribution

Desiccator Plenum Chamber For Uniform Gas Distribution

Multi-chamber desiccator cabinets include a perforated plenum to minimize back fill, ensure uniform gas distribution to all chambers and increase cabinet strength

Built-in Plenum Distributes Dry Gas to Each Chamber

Manual flowmeter or automated system controls nitrogen flow rates to maintain RH across entire cabinet. Built-in plenum distributes dry gas to each chamber.
Terra Universal Desiccator Cabinet Stainless Steel Door Frame

Doors - The First Failure Point of a Desiccator Cabinet

Terra’s stainless steel door frames eliminate the need for internal reinforcements, which create particle surfaces and compromise cleaning. Unlike other doors with glue-on anti-bow pieces, Terra’s doors use no adhesives. This eliminates particle traps, sources of outgassing—and extends the strength and service life of the desiccator.

Popular Accessories

For a full list of accessories, select a product then click Choose Accessories on that product page.
  • 3-inch Diameter Caster Set
    3-inch Diameter Caster Set
    Casters are easily retrofitted for mobility. Products can be rolled out of the way when cleaning or relocated as workflow changes.
  • Relative Humidity and Temperature Data Logger
    Humidity and Temperature Data Logger
    Provides a convenient record of storage conditions inside a Desiccator chamber-adjustable logging interval (hours to months), USB port for easy data download in several formats.
  • Dual Purge and NitroWatch nitrogen control systems maintain low-rh set-point inside a desiccator or glove box
    Dual Purge and NitroWatch
    Terra’s Dual Purge and NitroWatch relative humidity controllers maintain a low-RH set-point inside a desiccator or glove box; they provide variable purge control that ensures continuous positive pressure and eliminates nitrogen waste.
  • Nitrogen Generator Group
    Nitrogen Generator
    Terra’s Nitrogen Generators provide a continuous, reliable supply of clean, dry nitrogen up to 99% pure to eliminate dependence on bulky canisters to operate desiccators and glove boxes.
  • Ionizing Module Installed on Desiccator Cabinet
    Desiccator Cabinet Ionizing Module
    Ionizing modules are available for desiccator cabinets, glove boxes and other enclosures to ensure static-safe storage and processing (shown: ionizing unit on 2-chamber desiccator)
  • Powder-Coated Steel Stand for Small Desiccators, 4
    Small Powder-Coated Steel Desiccator Stand, 4"H
    Small 4"H powder-coated steel desiccator stand adjusts to fit cabinet snugly; optional casters simplify positioning and cleaning. Also available in stainless steel and 12" height.
Products similar to this one
  1. High-volume storage unit hold a full vacuum for 24 hours at room temperature (accessories not included) | 3308-11 displayed
    $301
    Usually Ships in 15 - 25 days
    Desiccator; Polycarbonate, 22" W x 22" D x 18" H, Secador Techni-Dome 360
Other products you may find relevant
  1. Closed-cell PVC foam gasketing withstands dry environment inside desiccators | 1100-26 displayed
    $37
    Usually Ships in 1 - 3 days
    Gasketing, Desiccator Door; 25 ft. long
  2. Shown on a reference grid of 1-inch (25mm) squares | 1100-27 displayed
    $67
    Usually Ships in 1 - 3 days
    Gasketing, Desiccator Door; 50 ft. long
  3. Shown with optional SS wire ssupports. | 3607-03 displayed
    $101
    Usually Ships in 1 - 3 days
    Stainless Steel Rack; for Tape and Reel Desiccator, 23.5''W x 7.75"D x 0.75''H
  4. Accuracy: 5% @ 25C from 10% to 90%RH | 5401-17 displayed
    $109
    Usually Ships in 1 - 3 days
    Psychrometer; Digital, Handheld, AAA Batteries
  5. Sealed outer shell is fabricated of static-dissipative PVC for additional ESD protection | 2650-99 displayed
    $5,451
    Usually Ships in 20 - 24 days
    Mobile Desiccator Cabinet; 1 Chamber, Static Dissipative PVC, 23.75" W x 28.875" D x 60.25" H ID
  6. Stores 16,382 temperature readings and 16,382 relative humidity measurements. | 9500-10 displayed
    $240
    Usually Ships in 1 - 3 days
    Data Logger; Relative Humidity/Temperature
  7. Qualification Documentation (IQ/OQ) for Terra Universal System
    Request Quote
    Usually Ships in 5 - 5 days
    Qualification Documentation (IQ/OQ) for Terra Universal System
  8. Digital thermometer with humidity indicator for cleanroom application. | 5401-34 displayed
    $209
    Usually Ships in 1 - 3 days
    Thermo-Hygrometer; Wireless, LCD, 8-Channel, with Remote Sensor
  9. The Portable CleanBooth™ wheels into position above a workbench or equipment to provide an ISO 5-compliant flow of HEPA-filtered air (flexible side panels and f | 1870-03A displayed
    From
    $2,572
    Some ship in 1 - 3 days
    Portable CleanBooth™; Vertical Laminar Flow
  10. DesiCart, Low Humidity Transport Carts features high-density polyethylene frame, steel rails, and a four chamber acrylic desiccator | 4002-50B displayed
    From
    $2,510
    Some ship in 23 - 31 days
    DesiCart™ Low-Humidity Transport Carts
  11. A convenient, contamination free, economical carrying container for moisture-sensitive devices | 9302-23B displayed
    From
    $455
    Some ship in 1 - 3 days
    Portable Desiccator Dry Boxes
  12. Sure-Grip EX safety can storage cabinets protect workers, reduce fire risks, and improve productivity by storing hazardous liquids in high performance | 2820-00A displayed
    From
    $532
    Some ship in 8 - 12 days
    Sure-Grip® Flammable Liquid EX Safety Can Storage Cabinets from Justrite
  13. Undercounter Flammable safety cabinets by Justrite includes dual vents with flame arresters located in the back | 1619-95 displayed
    From
    $548
    Some ship in 8 - 12 days
    Sure-Grip® EX Undercounter Flammable Safety Cabinets by Justrite
  14. Yellow Slimline safety cabinets by Justrite are fire resistant double wall, air insulated and welded steel construction | 1619-90 displayed
    From
    $587
    Some ship in 8 - 12 days
    Yellow Slimline Safety Cabinets by Justrite
  15. Sure-Grip EX deep SlimLine safety cabinets provides OSHA-, NFPA-compliant protection and containment of flammable materials | 1618-21 displayed
    From
    $938
    Some ship in 8 - 12 days
    Sure-Grip® EX Deep Slimline Safety Cabinets by Justrite
  16. Corrosive Storage by Justrite features two manual stainless steel doors with 3-point stainless steel bullet latching system | 2820-09A displayed
    From
    $629
    Some ship in 8 - 12 days
    Corrosive Storage Cabinets by Justrite
  17. Stainless steel BioSafe Cleanroom Clipboards provide non-shedding, durable, conductive surfaces, ideal for aseptic environments | 1350-00A-2 displayed
    From
    $58
    Some ship in 1 - 3 days
    BioSafe® Cleanroom Clipboards
  18. Palm-Sized Temperature/Humidity Meters available with built-in or probe sensors | 1401-17 displayed
    From
    $477
    Some ship in 10 - 16 days
    Palm-Sized Temperature/Humidity Meters
  19. PureFlow Laminar Transport Cart system provides an uninterrupted vertical laminar flow of HEPA-filtered air in the storage | 1529-64A displayed
    From
    $11,519
    Some ship in 20 - 24 days
    PureFlow™ Laminar Flow Transport Carts
  20. This all-stainless Steel Security Cabinet features a lock with fingerprint scanner for secure storage of pharmaceuticals | 1989-10 displayed
    From
    $2,262
    Some ship in 1 - 3 days
    Locking Pharmaceutical Security Cabinets
  21. Ionizing bars neutralize surface static charges, protecting sensitive materials and preventing particle buildup due to static cling
    From
    $414
    Some ship in 1 - 3 days
    Ionizing Bars
  22. This Ionizing Blow-off Gun neutralizes static surface charges and removes particles with a burst of clean air or nitrogen | 2005-55 displayed
    From
    $729
    Some ship in 1 - 3 days
    Cleanroom Ionizing Blow-Off Gun
  23. Designed with a compact and rugged enclosure, this chart recorder provides accurate record for temperature, humidity, and dew point | 4801-66 displayed
    From
    $489
    Some ship in 5 - 7 days
    Chart Recorders – Temperature, Humidity, and Dew Point
  24. Terra’s hygro-thermometer offers simultaneous display of temperature and humidity in a large LCD readout | 5401-21 displayed
    From
    $45
    Some ship in 1 - 3 days
    Hygro-Thermometers (Large Display)
  25. Curing/Drying Cabinets provide dual HEPA/carbon filtration | 6082-43A displayed
    From
    $4,012
    Some ship in 4 - 6 days
    HEPA/ULPA Filtered Curing/Drying Cabinets
  26. Nitrogen Generators provide a reliable source of clean, dry nitrogen, requiring only a compressed air source
    From
    $5,806
    Some ship in 1 - 3 days
    Nitrogen Generators
  27. Designed to provide reliable gas drying without the hassle and expense | 9082-01 displayed
    From
    $3,201
    Some ship in 1 - 3 days
    Dryex Gas Dryer
  28. Heated WhisperFlow Fan Filter Units (FFUs) provides a uniform flow of heated ULPA-filtered air for parts drying and other operations at above-ambient temperatur | 6601-24-UT displayed
    From
    $1,505
    Some ship in 10 - 14 days
    Heated Fan Filter Units
  29. Desiccator Trays, Stainless Steel
    From
    $183
    Some ship in 1 - 3 days
    Desiccator Trays, Stainless Steel
  30. Measures temperature from -40 to +212F | 3710-04A displayed
    Request Quote
    Usually Ships in 12 - 22 days
    Temperature/Relative Humidity Meter; Digital, Probe Sensor, Vaisala, Battery

On a tight schedule? Choose FasTrak 24/7 Priority Service to help meet your critical schedule for Terra-manufactured products, either before or after your order is placed.*

  • FasTrak 24/7 provides a 24/7 commitment to meet the shipping date YOU specify, regardless of quoted lead times.
  • FasTrak 24/7 assigns a dedicated production team plus a dedicated senior expeditor working three shifts to meet your delivery specification.
  • FasTrak 24/7 guarantees* to meet the agreed-to specified ship date.

Call for pricing. FasTrak service fees cover costs of additional services only, without additional profit.

 * Terra's FasTrak services limited guarantee: to ship on the ESD or date specified OR to refund up to 100% of FasTrak charges. This guarantee covers no direct, special, consequential or other damages and is strictly limited to up to 100% of the amount paid for FasTrak service. When a specified ship date is missed due to factors outside Terra's control (vendor performance, deliveries by shipping companies, etc.) and random factors such as accidents, the credit of up to 100% of the FasTrak 24/7 may not apply. FasTrak service requested after order placement will be quoted and accepted based on available time remaining before required ship date.

Hide
You need at least 2 products to compare Compare Clear All
Compare Products
