1590-60
Terra Part # 1590-60
Request Quote
Usually ships in 43-49 business days

Want it faster ? Read about FasTrak

Accessories related to Terra Part # 1590-60
6261
Vacuum Chamber; High Capacity, Aluminum, 29.375" W x 23.375" D x 16.75" H ID
Product Details
  • Available ISO Rated Designs: ISO 5, ISO 6, ISO 7, ISO 8
  • Maximum Vacuum: 29.9" Hg
  • 1.5" thick aluminum walls provide a strong seal
  • Includes dual mini ball valves and a 0-30" Hg
  • Optional cart available for storing vacuum pump beneath chamber
  • Unless otherwise specified, Unit Price includes packaging costs.

Type: High Capacity

Material: Aluminum

Width: 31"

Depth: 25"

Height: 19"

Maximum Vacuum: 29.9" Hg

Chamber Dimensions: 29.375" W x 23.375" D x 16.75" H

Chamber Width: 29.375"

Chamber Depth: 23.375"

Chamber Height: 16.75"

Unit of Measure: EA

Electrical Specifications: None

Weight, Product: 425 Lbs

Dimensions, Product: 31.37" W x 25.4" D x 18.8" H

Weight, Shipping: 495 Lbs

Dimensions, Shipping: 37"W x 31"D x 25"H

Package Type: Crate

Buy Accessories
  1. Releases pressure to prevent damage to samples  |  5235-11 displayed
    Vacuum/Pressure Relief Valve, Vacuum Chamber Quick Ship+ Available 57 in stock
    $141
    Increase Down Increase Up
  2. Dual metering valves allow purging of the chamber with nitrogen or other process gas before vacuum is applied  |  5235-09 displayed
    $262
    Increase Down Increase Up
  3. Welch 1397 Duoseal vacuum pump, belt-driven, oil-seal  |  7906-21 displayed
    $8,543
    Increase Down Increase Up
  4. Vacuum pump. Product details may differ.  |  7901-00 displayed
    Vacuum Pump; Rotary Vane, Pfeiffer, 120 V Ships Free Free shipping in contiguous USA
    $4,211
    Increase Down Increase Up
  5. Multpin feedthru installed in acrylic vacuum chamber.  |  5235-46 displayed
    $1,347
    Increase Down Increase Up
  6. Two-pin feed-thru installed in acrylic vacuum chamber.  |  5235-47 displayed
    $1,303
    Increase Down Increase Up
  7. Electrical power feed-through for vacuum chambers; custom configurations available upon request  |  5236-30 displayed
    Request Quote
    Increase Down Increase Up
  8. LFT/LFNT fluid feed-through for vacuum chambers; custom configuration available upon request  |  5236-31 displayed
    Request Quote
    Increase Down Increase Up
  9. Thermocouple feed-throughs for vacuum chambers; custom configuration available upon request  |  5236-32 displayed
    Request Quote
    Increase Down Increase Up
  10. Vaccum viewports for vacuum chambers; custom configuration available upon request  |  5236-33 displayed
    Request Quote
    Increase Down Increase Up
  11. Stainless Steel and powder-coated steel stands adjust to fit cabinets, desiccators and cleanroom equipment of any size.  |  1609-20 displayed
    $597
    Increase Down Increase Up
  12. Stainless Steel and powder-coated steel stands adjust to fit cabinets, desiccators and cleanroom equipment of any size.  |  1609-20 displayed
    $597
    Increase Down Increase Up
  13. Small 4"H stainless steel desiccator stand; optional casters simplify positioning and cleaning
    $624
    Increase Down Increase Up
  14. Small 4"H stainless steel desiccator stand; optional casters simplify positioning and cleaning
    $624
    Increase Down Increase Up
  15. O-ring Refresher  |  1618-82 displayed
    $43
    Increase Down Increase Up
  16. FasTrak 24-7 Expediting Service
    Request Quote
    Increase Down Increase Up
  17.  |  5235-29 displayed
    Request Quote
    Increase Down Increase Up
  18.  |  5235-23 displayed
    Mini Ball Valve, 1/4" MNPT, Nickle Plated Quick Ship+ Available 280 in stock
    $66
    Increase Down Increase Up
  19. Senses and indicates vacuums on 0-30 Hg scale  |  5235-10 displayed
    Vacuum Gauge 0-30HG, 2"dia, 1/4"NPT Quick Ship+ Available 130 in stock
    $322
    Increase Down Increase Up

Vacuum Chambers

  • Vacuum chambers animation Watch Terra's Vacuum Chamber Video
  • Powder-Coated Aluminum Vacuum Chamber with Model Powder-Coated Aluminum Vacuum Chamber
  • Powder-Coated Vacuum Chamber with Model Powder-Coated Aluminum Vacuum Chamber
  • Aluminum Vacuum Chamber Powder-Coated Aluminum Vacuum Chamber
Vacuum chambers animation

Features and Benefits

Powder-Coated Aluminum Vacuum Chamber Walls

One-inch-thick, powder-coated aluminum walls ensure chamber cleanliness and integrity while subject to vacuum up to 29.9”Hg.

Installed Vacuum Gauge and Metering Valves

Gauges and valves preinstalled on vacuum chambers allow vacuum application, monitoring, bleeding and backfilling (shown mounted on aluminum chamber).

Powder-Coated Aluminum Vacuum Chamber Gauge and Metering Valves Inlaid O-Ring

O-ring rests in a precision-routed channel for an optimal seal that prevents leakage.

Viewing Window for Vacuum Chamber

A sealed, 1”-thick acrylic window affords a view of the chamber’s contents. Optional tempered glass viewing window for optical testing.

Vacuum Chamber on Electric Height Adjusting Table

Electric height adjusting tables help easily position extremely heavy vacuum chambers to the right height to allow transfer of materials, or observe tests within the chamber.

Products Tailored to Your Cleanroom Environment

Provide Terra with your desired ISO Grade™ design. We will tailor the product to meet your criteria and certify it with a report appended to your invoice. Certificate includes all the necessary information to streamline audits and facility compliance.
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Universal Base Stands Offer Excellent Versatility

    Universal base stands support and stabilize various equipment sizes. Adjustable telescoping members allow for a precise fit. Choose between stainless and powder-coated steel to fit your desired application.
  • Universal Stand Adjusts to Fit a Wide Range of Equipment

    Terra's Universal stands easily adjust to fit a wide range of equipment. Multi-purpose stand frames are suitable for many types of cleanroom equipment, including refrigerators, freezers, incubators, ovens, and vacuum chambers.
  • Multi-pin Feedthrough

    Optional 25-pin connector can be used to monitor conditions within the vacuum chamber.
  • Coaxial SMA Feedthrough

    Double-ended, 50-ohm connectors allow small electronics to operate within the chamber.
  • Optional Vacuum Relief Valve

    Adjustable pressure relief valve limits vacuum levels within the chamber, allowing pressure to be maintained at user-configured point. (NOTE: Vacuum pump must remain in operation to maintain desired vacuum level).
  • Welch Rotary Vane Vacuum Pump

    This Rotary Vane vacuum pump offers high water vapor tolerance, light weight and high vacuum performance, making it ideal for many laboratory uses.
  • PC-Based Vacuum Control with Data Logging

    The eVAC Digital Vacuum Controller provides highly flexible control over vacuum levels by incorporating an electronically activated bleed valve, which adds the capability to reduce the applied vacuum.
