Epoxy Resin Work Stations
2903-PP-02 72037
Epoxy Resin Laboratory Table
Read more
Manufactured By: Terra Universal
Print
Want a quote quickly ?
Submit a QuickQuote requestProduct Details
Product Details
- 1"-thick, high-density epoxy surface with beveled edges
- Self-extinguishing, non-absorbent and corrosion-resistant
- Bacterial and fungal resistant
- Non-reactive and low-sheen uniform finish
- Ideal for use in high-volume biochemistry labs and proteomic research
Epoxy Resin Work Stations
Ergo Height Auto Adjustable Cleanroom Work Station
Operation of the ErgoHeight Auto-Adjusting Cleanroom Work Station Ergo Height Auto Adjustable Cleanroom Work Station ErgoHeight tables provide a 15" range of vertical motion to ensure personnel comfort without disrupting tabletop set-ups.
Features & Benefits
Features & Benefits
Epoxy Resin Table Specifications
Print Copy Copied
More Information
- Applications for Epoxy Resin Lab Tables: Proteomics, biochemistry, New Lab Set Up and Wet Chemistry
- Chemical Resistance Testing For Epoxy Resin Table Tops: Epoxy resin lab tabletops are individually tested for their corrosion resistance against organic compounds and volatile/non-volatile chemicals.
- Test temperature for Method A and B: 23° +/- 2°C (73° +/- 4°F
- Method A - Volatile chemicals A cotton ball saturated with the test solvent was placed in a one-ounce bottle (10 mm x 75 mm test tube or similar container). The bottle was inverted on the test material surface for a period of 24 hours.
- Method B - Nonvolatile chemicals Five drops (1/4 cc) of the test chemical covered with a 25mm watch glass were placed on the test material surface for a period of 24 hours. This method was used for all chemicals listed below, other than the solvents.
Evaluation Method
Epoxy resin material was exposed to chemicals for 24-hours. Exposed areas were washed with three substances in the following order: water, detergent solution and isopropyl alcohol. Then, the material was rinsed with distilled water and dried with a cloth. Samples are numerically rated as follows:- 0 - No Effect: No detectable change in the material surface.
- 1 - Good: Slight detectable change in color or gloss, but no change in function or life of the surface.
- 2 - Fair: Slight surface etching or severe staining. Clearly discernible change in color or gloss but no significant impairment of surface life or function.
- 3 - Poor: Pitting, cratering or erosion of the surface. Obvious and significant deterioration. Objectionable change in appearance due to discoloration.
Evaluation Results of Epoxy Resin Lab Table Work Surface on Compounds and Chemicals
| Chemical Tested* | Method | Black Onyx |
|---|---|---|
| Amyl Acetone | A | 0 |
| Ethyl Acetone | A | 0 |
| Acetic Acid 98% | B | 0 |
| Acetone | A | 1 |
| Acid Dichromate 5% | B | 0 |
| Butyl Alcohol | A | 0 |
| Ethyl Alcohol | A | 0 |
| Methyl Alcohol | A | 1 |
| Ammonium Hydroxide, 28% | B | 0 |
| Benzene | A | 1 |
| Carbon Tetrachloride | A | 0 |
| Chloroform | A | 1 |
| Chromic Acid 60% | B | 2 |
| Cresol | A | 0 |
| Dichloride Acetic Acid | A | 0 |
| Dimethylformamide | A | 0 |
| Dioxane | A | 0 |
| Ethyl Ether | A | 0 |
| Formaldehyde 37% | A | 0 |
| Formic Acid 90% | B | 0 |
| Furfural | A | 1 |
| Gasoline | A | 0 |
| Hydrochloric Acid 37% | B | 0 |
| Hydrofluoric Acid 48% | B | 2 |
| Hydrogen Peroxide 28% | B | 0 |
| Tincture of Iodine | B | 0 |
| Methyl Ethyl Ketone | A | 0 |
| Methylene Chloride | A | 0 |
| Mono Chlorobenzene | A | 0 |
| Naphthalene | A | 0 |
| Nitric Acid 20% | B | 0 |
| Nitric Acid 30% | B | 1 |
| Nitric Acid 70% | B | 1 |
| Phenol 90% | A | 0 |
| Phosphoric Acid 85% | B | 1 |
| Silver Nitrate, Saturated | B | 0 |
| Sodium Hydroxide 10% | B | 1 |
| Sodium Hydroxide 20% | B | 1 |
| Sodium Hydroxide 40% | B | 1 |
| Sodium Hydroxide Flake | B | 1 |
| Sodium Sulfide, Saturated | B | 2 |
| Sulfuric Acid 25% | B | 1 |
| Sulfuric Acid 85% | B | 2 |
| Sulfuric Acid 96% | B | 3 |
| Sulfuric Acid 85% and Nitric Acid 70%, Equal Parts | B | 3 |
| Toluene | A | 1 |
| Trichloroethylene | A | 0 |
| Xylene | A | 0 |
| Zinc Chloride, Saturated | B | 0 |
| *More information on independent test results available upon request. Call Terra Universal at 714-578-6100. | ||
Adjustable Telescoping Legs
Workstations include telescoping legs to enhance ergonomics, reduce shipping cost, integrate with existing tables or casework, and support multiple operators who require different work surface heights. Each telescoping workstation is tested to ensure a weight load of 1,200 pounds.
ErgoHeight Intuitive Controls
ErgoHeight compact control panel includes four buttons for user height presets and a digital display
High Caliber Hardware
Seemingly small details like latches, ports, glides and hinges are often overlooked or ignored by other manufacturers, and later become the point of costly recurring maintenance or equipment failure. Terra’s products are made of long lasting, cleanroom compatible, top tier hardware. Individual components are carefully designed and rigorously tested to guarantee the highest quality, durability, and craftsmanship.
Clean and Durable Powder Coat Finish
Terra’s signature white powder coat finish provides a high quality, durable barrier to protect against corrosion, plus a clean and attractive aesthetic. The advanced heat-fused formulation exceeds ASTM and ISO paint standards to resist chipping, scratching, fading, and wearing.
