Terra Part # 1538-30
$6,881
Usually ships in 25-29 business days

Want it faster ? Read about FasTrak

Accessories related to Terra Part # 1538-30
55147
Fume Hood; Protector XStream, 48" W x 37.7" D x 59" H, Labconco, 115 V

• Opti-Zone™ Baffle with tapered slots

• T8 fluorescent lighting (pre-wired) with vapor-proof design

• By-pass airflow design with variable air volume compatibility

• Eco-Foil™ Air Foil with aerodynamic Clean-Sweep™ airflow openings

• Cord-Keeper™ Slots located on left and right side of air foil

• ADA-compliant light and blower switches

• Total Exhaust CFM and Static Pressure Sash Opening-100% (28”) Open CFM, s.p. 0.29

• Total Exhaust CFM and Static Pressure Sash Opening-62.5% (18”) Open, CFM, s.p. 0.11

• Removable front and side panels, and front and interior service access panels for access to plumbing and electrical wiring.

• Contributes to LEED(R) credits for new construction as designated by United States Green Building Council

• Conformance: ANSI Z9.5, ASHRAE 110, ASTM E84, CAN/CSA C22.2, NFPA 45, SEFA 1, UL

Built-In Blower: No

Depth: 37.7"

Hood Design: Benchtop

Duplex Outlet: Optional

Frame Material: Powder-Coated Steel

Height: 59"

Light Fixture: Vapor-Proof

Manufactured by: Labconco

Manufacturer SKU: 110410000

Max Opening: 28"H

Model: Protector XStream

Sash Design: Manual/Sliding

Sash Height: 18"

Service Fixtures: Optional

Shield Type: Vertical

Type: Ducted

Width: 48"

Work Area Dimensions: 38.1"W x 27.2"D

Unit of Measure: EA

Dimensions, Product: 48" W x 37.7" D x 59" H

Dimensions, Shipping: 56" W x 44" D x 71" H

Electrical Specifications: 115 V, 10 A, 1,150 W, 50/60 Hz

Marks & Listings: UL, SEFA 1, NFPA 45, ASTM E84-09C, ASHRAE 110, AN

Package Type: Crate

Weight, Product: 440 lb

Weight, Shipping: 440 lb
