6603-15
Terra Part # 6603-15
$6,228
Usually ships in 25-26 business days

Want it faster ? Read about FasTrak

Terra Part # 6603-15
61849
$6,228
Usually ships in 25-26 business days

Want it faster ? Read about FasTrak

Product Details
  • Available Certified ISO Grade Designs: ISO 5, ISO 6, ISO 7, ISO 8
  • Flush-mount internal and external window panes are secured by the steel cleanroom panels
  • For use in Terra’s BioSafe All-Steel Cleanrooms
  • Designed for use in Steel BioSafe Cleanrooms only
  • Unique frame design seals flush against interior wall surface, eliminating surfaces that collect dust; cleaning is easy
  • Specify quantity, size and location on cleanroom order; Maximum width: 36"
  • Refer to drawing(s) for size and location
  • Standard vertical placement (unless otherwise indicated): 24" (610 mm) from window bottom to cleanroom floor
  • Since regulations vary considerably in different locations, Terra assumes no responsibility for meeting local building regulations, including fire and seismic codes.  Check your local planning department to see what regulations apply to your installation

Compatibility: BioSafe® Steel

Frame Material: Frameless

Window Frame: Frameless

Opening Width: 36"

Opening Height: 48"

Pane Area: 12 sq. ft.

Pane Material: Tempered Glass

Wall Thickness: 2" to 3.9"

Window Type: Double Pane

Unit of Measure: EA

Weight, Shipping: 268 lb

Features and Benefits

Customized to Your Wall Thickness

Visit our Pre-Engineered Product area to view existing designs available at discounted prices and faster lead times

Framed Double-Flush Cleanroom Window for Pharmaceutical Compounding Rooms

Dual-pane window sits flush with wall surface, design is free of cracks and crevices where contaminants can aggregate. Design meets USP and medical-grade requirements.

Framed Double-Flush Cleanroom Window

Framed design encases window panes with 304 Stainless Steel frame on the exterior. Glazing is recessed into the frame for a flush surface with the wall to minimize crevices where contaminants can collect.

BioSafe®: Terra's Ultimate Cleanliness Rating

Terra's BioSafe products are designed for the most critical applications: no gaps and crevices where microbes colonize, rounded corners for easy disinfection, won't produce contaminants during sterilization, and exceeds cGMP, IEST, ASTM and ISO 14644-1 requirements.

Products Tailored to Your Cleanroom Environment

Provide Terra with your desired ISO Grade™ design. We will tailor the product to meet your criteria and certify it with a report appended to your invoice. Certificate includes all the necessary information to streamline audits and facility compliance.

On a tight schedule? Choose FasTrak 24/7 Priority Service to help meet your critical schedule for Terra-manufactured products, either before or after your order is placed.*

  • FasTrak 24/7 provides a 24/7 commitment to meet the shipping date YOU specify, regardless of quoted lead times.
  • FasTrak 24/7 assigns a dedicated production team plus a dedicated senior expeditor working three shifts to meet your delivery specification.
  • FasTrak 24/7 guarantees* to meet the agreed-to specified ship date.

Call for pricing. FasTrak service fees cover costs of additional services only, without additional profit.

 * Terra's FasTrak services limited guarantee: to ship on the ESD or date specified OR to refund up to 100% of FasTrak charges. This guarantee covers no direct, special, consequential or other damages and is strictly limited to up to 100% of the amount paid for FasTrak service. When a specified ship date is missed due to factors outside Terra's control (vendor performance, deliveries by shipping companies, etc.) and random factors such as accidents, the credit of up to 100% of the FasTrak 24/7 may not apply. FasTrak service requested after order placement will be quoted and accepted based on available time remaining before required ship date.
