Product 2900-91-SS
$38,714
Usually ships in 25-31 business days

Want it faster ? Read about FasTrak

Designed in the USA

• Containment Room Dimensions: 6' W x 10' D x 8' H (1829 x 3048 x 2438mm)

• Ante-room Dimensions: 4' W x 10' D x 8' H (1219 x 3048 x 2438mm)

• Specified height is 8' (2438 mm) from the floor to filter face. FFUs add 13” (330 mm) overhead clearance to this measurement. To assure proper air flow and installation, allow an additional 11” (279 mm) between the top of the FFUs and the ceiling or other overhead obstruction (total of 24" - 610 mm - between the cleanroom filter face and the surrounding facility ceiling)

• Materials: Double-wall, insulated 304 Stainless Steel panels with radius corners provide clean, ISO 5-compatible interior surfaces that are easy to clean and sterilize

• To simplify USP compliance, specify optional Automated Environmental Control System, which monitors and logs room pressures, temperature and humidity; allows fan adjustment from control panel to balance room pressures, and issues alerts if levels fall out of spec

• Includes (3) HEPA filter/fan units, (2) fluorescent illuminators (1) 115VAC/60Hz duplex outlet, (1) power distribution module, (2) swing doors, (1) tempered-glass viewing window and FDA-approved silicone sealant for caulking internal seams

• Internal polycarbonate swing door creates a separate gowning antechamber

• Request UL Listing Declaration (order separately) for cleanroom electrical system, which helps meet municipal and other permitting requirements that may apply

• No floor included; room should be installed on a flat, sealed, non-particulating, non-porous, crevice-free surface, which can be caulked to the clean room frame to form a seal

• Air exhaust vents are adjustable to allow pressure balancing

• Compliance Notice: this clean room is built to the specifications of USP 797 as published in USP 40-NF 35; however, because practice standards vary from state to state and depend on compounding operations, Terra recommends consultation to evaluate suitability for your application

Application: USP 797 (Sterile)

Frame Material: Stainless Steel

Panel Material: 304 Stainless Steel

Electrical Specifications: 120 V, 1 Ph, 60 Hz

• Weight, Shipping 1,250 lb

• Dimension, Shipping

Unit of Measure: EA

Features and Benefits

USP Cleanroom Customization
USP 800 BioSafe Cleanroom, Custom Floor Plan

Affordable customization to unique requirements!

  • Terra’s modular designs allow versatile configurations using standard components, whether you need a small compounding enclosure or a multi-suite processing facility (shown: Stainless steel USP 800 multi-room hazardous materials cleanroom with plastic hardwall ISO 8 transition room)
  • Versatile plug-and-play Power Distribution Modules allow addition of ceiling fan/filter units and lights to meet any cleanliness requirement or to upgrade ISO levels or lighting levels after installation
  • Modular frame and panel designs, in several application-specific materials, adapt to any floor plan requirement
  • Automated fan controls simplify pressure balancing, Building Management System (BMS) integration, and certification of large, multi-suite facilities
  • Stand-alone A/C modules or integration with existing air handling system
  • Negative-pressure plenums and exhaust fans accommodate hazardous materials compounding requirements (USP 800)
  • Consultation services available to meet USP 797 and 800 and FDA/cGMP requirements
  • Terra’s full engineering services adapt designs to accommodate unique equipment or facility integration challenges

Call or submit a QuickQuote Form for assistance with a modular cleanroom tailor-made to your application!

Smooth Interior Walls

Smooth steel BioSafe cleanroom panels with radius corners simplify cleaning and stand up to IPA and other sterilizing agents.

Sterile Buffer Room

Swing door separates ISO 7 Buffer room from ISO 8 Anteroom; ceiling HEPA fan/filters meet USP particle and pressure differential requirements.

LED Light Panels

Energy-efficient LED lights provide bright lighting without generating excessive heat inside the cleanroom.

Containment Exhaust Plenum

Negative-pressure containment cleanrooms include exhaust plenums that route air to floor- or ceiling-mount fans, protecting the external environment from hazardous materials inside the cleanroom.

BioSafe Windows

Dual-pane polycarbonate window is flush with the wall surface and provides a full view of the compounding operation.

Available Environmental Control System

Standard cleanroom comes with analog pressure gauge and on/off controls; optional touchscreen FFU controller monitors, controls and logs internal pressure, as well as displaying temperature and RH.

Partitioned Anteroom

Anteroom meets USP pressure and cleanliness requirements while providing a convenient gowning area (shown with optional no-touch hand washer/dryer)

Germicidal UV Lamp Sanitizes Labs, Cleanrooms

UV-C Germicidal Lamp installs on a cleanroom ceiling grid for line-of-sight room disinfection; safety occupancy sensor prevents personnel exposure.

BioSafe®: Terra's Ultimate Cleanliness Rating

Terra's BioSafe products meet design and material standards that go far beyond conventional cleanroom requirements. Developed specifically for aseptic requirements in bio-pharmaceutical cleanrooms, these items incorporate a range of features that minimize particle generation and accumulation and inhibit microbial growth.

Popular Accessories

For a full list of accessories, select a product then click Choose Accessories on that product page.
  • WhisperFlow Laminar Fan and Filter Units (FFUs)
    Equipment enclosures can be equipped with any number of fan/filter units to provide laminar airflow with HEPA or ULPA filtration
  • In-Wall Utilities Plumbing
    Plumbing for utilities can be easily installed within the BioSafe wall panels
  • Roll-Up Door Pas-Through Chamber
    Roll-Up Door Pass-Throughs with interlocked doors
  • Cleanroom Access and Automated Fan Controls
    Standard panel include pressure gauge, on/off and night switches; security system adds access restriction; automated fan system monitors and controls fan speed, pressure, temperature and RH.
  • BioSafe Pass-through Chambers
    Pass-through chambers, available for BioSafe Cleanrooms, include interlocked doors that allow contamination-free sample transfer.
  • Germicidal UV Lamp Sanitizes Labs, Cleanrooms
    UV-C Germicidal Lamp installs on a cleanroom ceiling grid for line-of-sight room disinfection; safety occupancy sensor prevents personnel exposure.

On a tight schedule? Choose FasTrak 24/7 Priority Service to help meet your critical schedule for Terra-manufactured products, either before or after your order is placed.*

  • FasTrak 24/7 provides a 24/7 commitment to meet the shipping date YOU specify, regardless of quoted lead times.
  • FasTrak 24/7 assigns a dedicated production team plus a dedicated senior expeditor working three shifts to meet your delivery specification.
  • FasTrak 24/7 guarantees* to meet the agreed-to specified ship date.

Call for pricing. FasTrak service fees cover costs of additional services only, without additional profit.

 * Terra's FasTrak services limited guarantee: to ship on the ESD or date specified OR to refund up to 100% of FasTrak charges. This guarantee covers no direct, special, consequential or other damages and is strictly limited to up to 100% of the amount paid for FasTrak service. When a specified ship date is missed due to factors outside Terra's control (vendor performance, deliveries by shipping companies, etc.) and random factors such as accidents, the credit of up to 100% of the FasTrak 24/7 may not apply. FasTrak service requested after order placement will be quoted and accepted based on available time remaining before required ship date.
